Introduction
Package
Contents

Installation

This guide describes how to set up the 3Com
Gateway Voice Expansion Unit (3C100XF) with your
OfficeConnect Gateway base unit – either an OfficeConnect
Gateway Data unit or an OfficeConnect Gateway Data and Voice
unit.
The OfficeConnect Gateway Voice Expansion Unit contains eight
POTS voice ports (POTS – Plain Old Telephone System) that can
be set up and configured to work with all versions of the
OfficeConnect Gateway. When connected to a Data version of the
OfficeConnect Gateway, it provides support for 8 simultaneous
POTS calls. When connected to a Data and Voice version, it
increases support to 12 simultaneous POTS calls.
Unpack the contents of your package, and ensure that it
contained the following items:
• AC/DC, 18 watt Power Adapter and Power Cord
• One Expansion Cable, RJ-45 (CAT-5), 18 inches, Green
• One RJ-11, 7-ft telephone cable, Silver
• Rubber feet
• Stacking clip
When installing your OfficeConnect Gateway Voice Expansion
Unit, make sure of the following:
• Unit is out of direct sunlight and away from sources of heat.
• Cabling is away from power lines, fluorescent lighting fixtures,
and sources of electrical noise such as radios, transmitters and
amplifiers.
• Water or moisture cannot enter the case of the unit.
• Air flow around the unit and through the vents in the side of
the case is not restricted. A minimum of 1 in. (2.54 cm ) clear-
ance is recommended.
For desktop use, the four self-adhesive rubber feet help to stabi-
lize your unit and prevent sliding. Attach the feet to the marked
areas at each corner of the underside of your unit.
In addition, the stacking clip provided may be used for stacking
the OfficeConnect Gateway Voice Expansion Unit with your
OfficeConnect Gateway, as well as other OfficeConnect products.
You can stack up to a maximum of four units.
® OfficeConnect ®
1
