NEC MultiSync LCD195NX User Manual page 7

Figure S.1
Figure S.3
12 mm
M4
4 x 12 mm with lock
washer and flat washer
100 mm
Figure F.1
Controls
OSD (On-Screen Display) control buttons on the front of the monitor function as follows:
1. Basic function at pressing each key
Button
At No OSD Showing OSD.
showing
At OSD showing Go to Adjustment stage.
(Icon selection stage)
At OSD showing Go to Icon selection stage.
(Adjustment stage)
01_English
Figure S.2
Thickness of Bracket (Arm)
2.0~3.2 mm
100 mm
–
SELECT
Shortcut to Bright adjust
window.
Cursor goes to left.
Adjust value decrease or
Cursor for adjust goes to
left.
3
Remove Monitor Stand for Mounting
To prepare the monitor for alternate mounting purposes:
1. Place hands on each side of the monitor and lift up to the highest
position. Remove the cable cover (Figure S.1).
NOTE: If you have difficulty removing the cable
cover, please push the lower opening
upward to remove it, as shown in the
figure beside.
2. Disconnect all cables.
3. Place monitor face down on a non-abrasive surface (Figure S.2).
NOTE: Handle with care when monitor facing down, for avoiding
the damage to the front buttons.
4. Remove the 2 screws connecting the stand to the monitor
(Figure S.2).
5. Remove the stand having three hooks toward direction
(Figure S.3).
The monitor is now ready for mounting in an alternate manner.
6. Connect the cables to the back of the monitor.
7. Reverse this process to re-attach stand.
NOTE: Use only VESA-compatible alternative mounting method.
Handle with care when removing stand.
Flexible Arm Installation
This LCD monitor is designed for use with a flexible arm. To mount
the monitor to a flexible arm:
1. Follow the instructions on how Remove Monitor Stand for
Mounting to remove the stand.
2. Use the 4 screws and attach the arm to the monitor (Figure F.1).
NOTE: The LCD monitor should only be used with an approved arm
(e.g. GS mark). To meet the safety requirements, the
monitor must be mounted to an arm, which guaranties the
necessary stability under consideration of the weight of the
monitor.
4 Screws (4M)
(Max Depth: 8 mm)
Weight of LCD assembly: 5.0 kg (MAX)
+
Shortcut to Volume adjust
window.
Cursor goes to right.
Adjust value increase or
Cursor for adjust goes to
right.
English-3
1/10/07, 8:38 AM
1<->2 / RESET
Input signal select.
Reset operation.
Mute off/on switch on
Volume adjustment window.
