  • Page 1 MultiSync LCD195NX User’s Manual...

  • Page 2: Declaration Of The Manufacturer

    NERGY endorsement of any product or service. ErgoDesign is a registered trademark of NEC Display Solutions, Ltd. in Austria, Benelux, Denmark, France, Germany, Italy, Norway, Spain, Sweden, U.K.. IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of International Business Machines Corporation.

  • Page 3: For The Customer To Use In U.s.a. Or Canada

    This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. U.S. Responsible Party: NEC Display Solutions of America, Inc. Address: 500 Park Blvd, Suite 1100 Itasca, Illinois 60143 Tel.

  • Page 4: Quick Start

    Contents Your new NEC MultiSync LCD monitor box* should contain the following: • MultiSync LCD monitor with height adjustable stand • Power Cord • Video Signal Cable (15-pin mini D-SUB male to 15-pin mini D-SUB male) • Video Signal Cable (DVI-D to DVI-D) •...
  • Page 5 3. Place hands on each side of the monitor to tilt the LCD panel 30-degree angle and lift up to the highest position (Figure C.1). 4. Connect all cables to the appropriate connectors (Figure C.1). 5. For successful cable management, place the cables in this order into the cable management: Power cord and DVI cable (Figure C.2).

  • Page 6: Raise And Lower Monitor Screen

    10. Connect the power cord to the power outlet (Figure E.1). NOTE: If you have difficulty removing the cable cover, please push the lower opening upward to remove it, as show in Figure E.2. NOTE: Please refer to Caution section of this manual for proper selection of AC power cord.

  • Page 7: Remove Monitor Stand For Mounting

    Remove Monitor Stand for Mounting To prepare the monitor for alternate mounting purposes: 1. Place hands on each side of the monitor and lift up to the highest position. Remove the cable cover (Figure S.1). NOTE: If you have difficulty removing the cable cover, please push the lower opening upward to remove it, as shown in the figure beside.

  • Page 8: Flexible Arm Installation

    Flexible Arm Installation This LCD monitor is designed for use with a flexible arm. To mount the monitor to a flexible arm: 1. Follow the instructions on how Remove Monitor Stand for Mounting to remove the stand. 2. Use 4 screws and attach the arm to the monitor (Figure F.1). NOTE: The LCD monitor should only be used with an approved arm (e.g.
  • Page 9 Controls OSD (On-Screen Display) control buttons on the front of the monitor function as follows: 1. Basic function at pressing each key – SELECT 1<->2 / RESET Button At No OSD Shortcut to Bright adjust Shortcut to Volume adjust Input signal select. Showing OSD.
  • Page 10 AUDIO Control the sound volume of speakers and headphone. To mute the speaker sound, press the 1<->2/RESET key. BRIGHTNESS Adjusts the overall image and background screen brightness. CONTRAST Adjusts the image brightness in relation to the background. AUTO CONTRAST (Analog Input only) Adjusts the image displayed for non-standard video inputs.

  • Page 11: Monitor Info

    OSD LOCK OUT This control completely locks out access to all OSD control functions without Brightness and Contrast. When attempting to activate OSD controls while in the Lock Out mode, a screen will appear indicating the OSD are locked out. To activate the OSD Lock Out function, press “1<->2/ RESET”, then “+” key and hold down simultaneously.

  • Page 12: Recommended Use

    As with all personal display devices, NEC DISPLAY SOLUTIONS recommends displaying moving images and using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
  • Page 13 CORRECT PLACEMENT AND ADJUSTMENT OF THE MONITOR CAN REDUCE EYE, SHOULDER AND NECK FATIGUE. CHECK THE FOLLOWING WHEN YOU POSITION THE MONITOR: • For optimum performance, allow 20 minutes for warm-up. • Adjust the monitor height so that the top of the screen is at or slightly below eye level. Your eyes should look slightly downward when viewing the middle of the screen.

  • Page 14: Specifications

    Specifications Monitor Specifications MultiSync LCD195NX Monitor Notes LCD Module Diagonal: 48 cm/19 inches Active matrix; thin film transistor (TFT) Viewable Image Size: 48 cm/19 inches liquid crystal display (LCD); 0.294 mm dot Native Resolution (Pixel Count): 1280 x 1024 pitch; 300 cd/m white luminance, 1000:1 contrast ratio, typical;...
  • Page 15 Features Reduced Footprint: Provides the ideal solution for environments requiring superior image quality but with size and weight limitations. The small footprint and low weight allow it to be moved or transported easily from one location to another. Colour Control System: Allows you to adjust the colours on your screen and customize the colour accuracy of your monitor to a variety of standards.

  • Page 16: Troubleshooting

    As with all personal display devices, NEC DISPLAY SOLUTIONS recommends displaying moving images and using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use.
  • Page 17 TCO’03 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the impact on our natural environment.

  • Page 18: Manufacturer's Recycling And Energy Information

    Manufacturer’s Recycling and Energy Information NEC DISPLAY SOLUTIONS is strongly committed to environmental protection and sees recycling as one of the company’s top priorities in trying to minimize the burden placed on the environment. We are engaged in developing environmentally- friendly products, and always strive to help define and comply with the latest independent standards from agencies such as ISO (International Organisation for Standardization) and TCO (Swedish Trades Union).
