STEREO CASSETTE TAPE DECK
X-W320
INSTRUCTION MANUAL
KENWOOD CORPORATION
B60-3265-08 MA (K, P, Y, M, I, C, X, T)
MC
97/12 11 10 9 8 7 6 5 4 3 2 1 96/12 11 10 9 8 7

Advertisement

Table of Contents
loading

Related Manuals for Kenwood X-W320

Summary of Contents for Kenwood X-W320

  • Page 1 STEREO CASSETTE TAPE DECK X-W320 INSTRUCTION MANUAL KENWOOD CORPORATION B60-3265-08 MA (K, P, Y, M, I, C, X, T) 97/12 11 10 9 8 7 6 5 4 3 2 1 96/12 11 10 9 8 7...

  • Page 2: Introduction

    Caution : Read this section carefully to ensure safe operation. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. X-W320 (En) AC 110 - AC 220 - 120V ‘...

  • Page 3: Table Of Contents

    Specifications ... 35 System control cord (1) * AC plug adaptor (1) Introduction X-W320 (En) carefully to ensure safe operation. * Use to adapt the plug on the power cord to the shape of the wall outlet. (Accessory only for regions where...

  • Page 4: Important Safeguards

    Any mounting of the appliance should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer. An appliance and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn. X-W320 (En)
  • Page 5 1. Item 3 is not required except for grounded or polarized equipment. 2. Item 17 and 18 are not required except for units provided with antenna terminals. 3. Item 17 complies with UL in the U.S.A. IMPORTANT SAFEGUARDS X-W320 (En)

  • Page 6: Information That You Should Know On Cassette Deck And Tape

    In such a case, insert a pencil into the reel hole and wind the reel hub to remove the slack. 2. Endless tapes Do not use an endless tape, as this could damage the mechanism of the unit. X-W320 (En)

  • Page 7: Maintenance

    TO MAKE COPIES OF TAPES OR DISCS WITHOUT THE PERMISSION OF THE COPYRIGHT OWNERS. ANYONE WISHING TO COPY COMMERCIALLY AVAILABLE TAPES OR DISCS SHOULD CONTACT THE MECHANICAL COPY- RIGHT PROTECTION SOCIETY LIMITED OR THE PER- FORMING RIGHTS SOCIETY LIMITED. X-W320 (En)

  • Page 8: System Connections

    *CD player If operation is not possible or erroneous display appears even though all connections have been made properly, reset the microcomputer referring to “In case of difficulty”. To wall AC outlet is variable depending on areas. X-W320 (En) ¤...
  • Page 9 For the connection with the “SERIES 21” system, please also read the instruction manual provided with the AV CONTROL CENTER (optional) or Receiver (optional). 1. Do not connect system control cords to any components other than those specified by KENWOOD. It may cause a malfunction and damage your equipment.

  • Page 10: Names And Functions Of Parts

    Peak level indicators (Dolby NR reference level) DUBB. NOR. (SP) HIGH DOLBY NR * * * * * STANDBY COUNTER STANDBY indicator Display STEREO DOUBLE CASSETTE DECK X-W320 DUBBING REV. MODE NORM. DOLBY NR CCRS POWER REC LEVEL RESET ¡...

  • Page 11: Preparation For Playback (Recording)

    TYPE Deck B direction indicators. 6 (dB) DUBB. NOR. (SP) HIGH CCRS O.T.E. DOLBY NR 0 0 0 0 STANDBY COUNTER after having played (or recorded) both sides. recorded both sides. having played (or recorded) a single side. X-W320 (En)

  • Page 12: Listening To Cassette Tapes

    Press the 7 key to stop fast tape winding. Do not press the 0 button until the tape has stopped completely. Press simultaneously. Press simultaneously. Tape is wound until counter reading near “0000” where it stops. X-W320 (En) ¡ ¡ ¡...

  • Page 13: Relay Playback

    3 DOLBY NR “C”: Noise reduction with higher performance. Select the Dolby NR mode according to the tape recording status. The playback starts with the deck the play key of which is pressed. Listening to cassette tapes repeated. B is repeated. X-W320 (En)

  • Page 14: Convenient Music Search (Dpss)

    : Keys and control used in the operations described on this page. To play the tune being played from the be- ginning ¡ To play the tune located 4 tunes behind ¡ X-W320 (En) ¡ Press once during the playback. ¡ Press 5 times during the playback.

  • Page 15: Rewind & Play Operation

    Dash & Play, the other deck starts Dash & Play for 16 times, after which it stops. ¡ Press the 7 key to stop playback and cancel this operation. Convenient music search (DPSS) stops. stops. X-W320 (En)

  • Page 16: How To Record (Deck B Only)

    The deck enters the stop mode automatically when the tape has been recorded till the end. : Keys and control used in the operations described on this page. 0dB. 6 (dB) - 1 4 d B Recording level display. X-W320 (En)

  • Page 17: To Pause Recording Temporarily

    Recording starts. How to record (Deck B only) 1 Stop the tape transport. 2 Stop playing the source component. Tape stops after 2 sec. of transport. Tune to be re-recorded. Recorded tune Re-recording Blank of 4 sec. or more. X-W320 (En)

  • Page 18: Tape Dubbing Operation (Deck A \ Deck B)

    Both decks A and B enter the stop mode. : Keys and control used in the operations described on this page. High-speed dubbing: Dubbing at about twice the normal speed. DUBB. NOR. lights up. DUBB. HIGH lights up. DUBB. DUBB. NOR. X-W320 (En) HIGH...

  • Page 19: Synchro Playback/Recording

    Synchro playback/recording By system-connecting this unit with the AV CONTROL CENTER of KENWOOD “SERIES 21” system (optional) or a KENWOOD CD player (optional) through a system control cord, the convenient system control operations can be used as described below. Preparation 1 Turn this unit ON.

  • Page 20: Cd Single-Track Recording (O.t.e.) (Deck B Only)

    To record another track ... Repeat steps 1 and 2. Pressing the 7 key of the CD player stops the CD player and the cassette deck. Pressing the 7 key of the cassette deck also stops the cassette deck and CD player. Synchro playback/recording X-W320 (En) Lights up. O.T.E.

  • Page 21: Cd All-Track Recording (O.t.e.) (Deck B Only)

    “How to record”. Pressing the 7 key of the CD player stops the CD player and the cassette deck. Pressing the 7 key of the cassette deck also stops the cassette deck and CD player. Synchro playback/recording X-W320 (En) Lights up. O.T.E.

  • Page 22: Cd Synchro Recording (Deck B Only)

    CD player does not stop. Synchro playback/recording : Keys and control used in the operations described on this page. 4 Put the CD player in pause mode. Press the 6 key of the CD player. X-W320 (En)

  • Page 23: Recording Of Cd Playback (Ccrs) (Deck B Only)

    The CCRS indicator blinks, and actual recording starts in about 20 to 200 seconds (after creating a non-recorded blank of about 8 seconds). After recording, the cassette deck and CD player enter the stop mode automatically. Synchro playback/recording X-W320 (En)

  • Page 24: System Remote Control Operation

    The remote control unit (hereinafter referred to as the RC) shown below is provided with the AV CONTROL CENTER (optional) or Receiver (optional) of KENWOOD “SERIES 21” system. RC operation is possible when the “SERIES 21” components are connected with this unit through a system control cord and the system components are in standby mode.
  • Page 25 The graphical remote control unit (hereinafter referred to as the GRC) shown below is provided with the AV CONTROL CENTER (optional) or Receiver (optional) of KENWOOD “SERIES 21” system. GRC operation is possible when the “SERIES 21” components are connected with this unit through a system control cord and the system components are in standby mode.
  • Page 26 Main Menu Source Tuner Tape1 TapeA Tuner Set Up Confirm Return Sat. VCR1 VCR2 TapeB Cable Sat. Tape 1 Single Dual X-W320 (En) Input Source Tape1 TapeA Set Up Confirm VCR1 VCR2 TapeB Tape1 VCR1 Cable VCR2 Reset Input Source Tape1...
  • Page 27 Fast tape winding in the \ direction. ¡ To stop playback Do not press the 0 button until the tape has stopped completely. System remote control operation X-W320 (En) 1 Stop playback. press the ENTER key. Select the icon and press the ENTER key.
  • Page 28 When the 7 key of the cassette deck is pressed (or the & icon is selected and the ENTER key is pressed ), the cassette deck stops but the CD player does not. System remote control operation X-W320 (En)
  • Page 29 Pressing the 7 key of the cassette deck (or selecting the cassette deck & icon and pressing the ENTER key) stops the cassette deck and the CD player. System remote control operation X-W320 (En) Lights up. O.T.E. Lights up. O.T.E.
  • Page 30 CCRS Program-edit recording is not possible when tracks of more than one CD are programmed using a Carrousel type CD player. After recording, the cassette deck and CD player enter the stop mode automatically. System remote control operation X-W320 (En)
  • Page 31 Main Menu Source Tuner Tape1 TapeA Tuner Set Up Confirm Return VCR1 VCR2 TapeB Cable Sat. VCR1 Setup Sat. O.T.E. DVD/6ch Input CCRS Sound Speaker X-W320 (En) Input Source Tape1 TapeA Set Up Confirm VCR2 TapeB Tape1 VCR1 Cable VCR2 Reset...

  • Page 32: In Case Of Difficulty

    The tape is stretched or wrinkled. The recording level was too high. A tape recorded with distorted sound is being played. X-W320 (En) Turn the power switch on and off again while pressing the Stop key on deck B. Please note that resetting microcomputer clears contents stored in and returns it to the condition when it left the factory.
  • Page 33 An attempt is made to play a tape using a cassette deck which is recording something. In case of difficulty X-W320 (En) Remedy Use a cassette with unbroken tab or close the hole. Close the cassette holder completely.

  • Page 34: Glossary

    4. After recording (when the CD player is stopped or when the tape has run out), both the cassette deck and CD player stop. CCRS Cassette deck Automatic recording level setting. » CD player X-W320 (En)

  • Page 35: Specifications

    Weight (Net) ... 4.8 kg (10.6 lb) 1. KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice. 2. The full performance may not be exhibited in an extremely cold location (under a water-freezing temperature).
  • Page 36 For your records Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided below. Refer to the model and serial numbers whenever you call upon your dealer for information or service on this product.
