Marshall Amplification MM1 Owner's Manual

OWNER'S MANUAL
MODELS MM1, MM1C - HEAT STATION
MANUFACTURER'S INTRODUCTION
The Model MM1 Heat Station features Marshall's own
ThermoGlo™ heating technology. Heat radiates from
every square inch of the upper flat plate heating surface.
This eliminates the need to clean intricate calrod, wire and
reflector assemblies. This unit is equipped with an
accessory 120 volt receptacle at the back which is fused
for a maximum of 5 amperes. It may be used for powering
a timer. This receptacle is furnished only on Model MM1.
The MM1C Heat Station is equipped with an infinite
switch to control the temperature on the ThermoGlo™.
110843MM1 RV082799
Copyright © 1999 Marshall Air Systems, Inc.
All Rights Reserved.
Supplier Name: MARSHALL AIR SYSTEMS, INC.
Address: 419 Peachtree Drive South
Charlotte, NC 28217
Model#: ___________________
Serial #': ___________________
___________________
___________________
Date Received: ___________________
Date Installed: ___________________
Telephone #: 704-525-6230
800-722-3474 Customer Service
Fax #: 704-525-6229
Service Referral #: 800-722-3474
Local Service: ___________________
Local Service #: ___________________
GENERAL SPECIFICATIONS
Models: MM1, MM1C Heat Station
Height: 19-1/4"
Width: 13"
Depth: 23-1/4"
Electrical: 110/120 volts, AC 840 watts,
50/60 Hz, 7 amps and up to 5
amps on accessory receptacle
220/240 volts, AC 900 watts,
50/60 Hz, no accessory
receptacle
Power Cord: 6 ft 3 wire ground type UL rated
Weight: 25 lbs.
Approvals: UL and NSF
