Helioscreen NEO Installation Manual page 5

2.4 MOUNTING HEIGHT AND POSITION OF THE BRACKETS
DeterMination of the Mounting height for wall-MounteD awningS:
The mounting height depends on the extended length and inclination of the awning. Please refer to the drawing on the right for
basic orientation. Always ensure that there is sufficient headroom.
requireD MiniMuM nuMber of trl bracketS:
The following tables indicate the number of standard supplied brackets required for mounting the NEO awning to a con-crete
base using the wall bracket and bracket plates.
Standard number of supplied brackets for the wall/ceiling bracket for mounting on a concrete base
Projection (mm)
1100 - 4000
1500
2000
2500
3000
3500
Projection (mm)
1100 - 4000
1500
2000
2500
3000
3500
www.helioscreen.com.au | Phone 1300 766 319
projection in mm
4001 - 6000
2 3
2 3
2 3
2 3
2 5
Standard number of brackets supplied for mounting using a bracket plate
4001 - 6000
2 3
2 3
2 3
2 3
2 3
Mounting height: The awning can
produce crushing forces and shear stresses,
for instance between the drop profile and the
casing, on the jointed arms and at the point
where different profiles meet.
In the interest of human safety, the mounting
height must be at least 2.50m. If the situ-
ation requires a mounting height less than
the stated minimum height, it is necessary
to operate the awning manually or with a
switch mounted at a location from where the
moving parts can be observed.
The drop profile must reflect a minimum
distance of 40 cm from fixed objects.
Width (mm)
6001 - 8000 8001 - 12000
4 6
4 6
4 6
4 6
4 10
Width (mm)
6001 - 8000 8001 - 12000
4 6
4 6
4 6
4 6
4 6
Helioscreen Neo
12001 - 14000
9
9
9
9
15
12001 - 14000
9
9
9
9
9
• INSTALLATION GUIDE | 5
