Display On/Off

The llA34 has only four front-panel contmols-the display on/off buttons.
Pressing a display on/off button will cause its chamwL and signal, to be
displayed or removed from the display (the function "toggles"). When a
channel is displayed, its label ((311, Cl-I 2, CK 3, or CH 4) will be lighted.
Selecting Coupling, HF Limit, and Impedance
To select the desired setting for Coupling, FIF Limit, 0~ Impedance, proceed as
follows:
lb.
3 .
If several traces are diiplayed, select a channel by touching the desired
trace description at the top of the at.
Touch the desired function's label. Successive touches will change its
state.
SEE, or PG. This button-pre%
