F.

Check operation

Dura Safe
SURE CONNECT
TM
Kits Make Installation Easy
Provides 4 1/2"
clearance between
dryer and wall
Snap-Lock fittings
Total kit length
8 feet
Additional vent can
be snapped between
sections for
Part #4396028
longer runs
Kit Contains:
2- 4' vent sections with attached close elbows
1- Wall plate for close clearance installations
2- 4" clamps
.
Dura Safe and Sure Connect are Trademarks of Whirlpool, U.S.A.
Panel G
1.
Check that you:
did not skip any steps.
installed all parts.
properly installed dryer legs.
leveled dryer.
have all the tools you started with.
Periscopes For Offset
TM
Outlets, Tight Installations
Vent Kit
Provides 2 1/2" clearance
between dryer and wall
Great for closet
installations
0"-18", 18"-29" or
29"- 50" periscopes
include one male
snap-lock fitting,
one extra long
draw-band collar
and one clamp
Use when vent outlets
overlap or are offset
Excess length can
be trimmed to fit
18"-29" and 29"-50" Periscope
Swivel collar
wall connection
Telescoping
sections
Beveled edges
allow corner
installations
18"-29" : Part #4396011
2
1
/
"
2
0"-18" : Part #4396037
18"-29" : Part #4396011
29"-50" : Part #4396014
0"-18" Periscope
Part #4396037
Sections separate,
fittings can face
same or opposite
Swivel collar
Extra long
band-clamp
for dryer
connection
29"-50" : Part #4396014
2.
Plug power supply cord into grounded
outlet or connect direct wire to power supply.
Turn power supply on.
3.
Read the Use and Care Guide to fully
understand your new dryer. Select a full heat
cycle (not the air cycle) and start dryer. After
five minutes, open dryer door. You should feel
heat inside dryer.
If dryer does not operate properly, check the
following:
electrical supply is connected.
house fuse is intact and tight; or circuit
breaker has not tripped.
dryer door is closed.
controls are set in a running or "On"
position.
start button has been pushed firmly.
If dryer makes an unusual noise, check the
following:
dryer is level.
For more information,
or to easily place your
order, call
1-800-442-9991
To have your venting
professionally installed,
call
1-800-253-1301
for the nearest
authorized service
provider.
