Prepare Dryer - Whirlpool LEV4634JQ0 Installation Instructions Manual

Hide thumbs

Advertisement

Table of Contents
Now start installation
See installation steps for details.
D.
Change door
swing.
SLIDE DRYER ONTO
CARDBOARD OR
HARDBOARD BEFORE
MOVING ACROSS TO
PREVENT FLOOR
DAMAGE.
A.
Install vent
system
(new installation)
B.

Prepare dryer

Panel C
(If installing washer and dryer, install dryer first.)
B.
E.
Remove tape.
Check that
dryer is level.
B.
Install feet.
1.
Put on safety glasses and gloves.
2.
Install exhaust
hood. Use caulking
compound to seal exterior
wall opening around
exhaust hood.
Use two or more people to move and
install dryer.
Failure to do so could result in back or
other injury.
1.
Remove tape from dryer cabinet.
Open dryer door and remove tape from dryer
drum. (Not all dryer drums are taped.) Remove
drying rack, if included. Turn dryer drum
counterclockwise to make sure all tape was
removed. Wipe drum with damp cloth to
remove any dust.
2.
Take two cardboard corners from dryer
carton and place them on floor in back of dryer.
Firmly grasp body of dryer and gently lay it on
its back on the cardboard corners.
F.
Check operation.
A.
Install vent system.
WARNING
Excessive Weight Hazard
F.
Turn on
power supply.
C.
Disconnect power supply.
Make electrical connection.
E.
Connect vent to
dryer.
3.
Connect exhaust vent to hood.
(Exhaust vent MUST fit inside hood.) Secure
vent to hood with clamp.
4.
Run exhaust vent to dryer location.
Use the straightest path possible. (See Panel B.)
Use clamps to seal all joints.
diamond
marking
3.
Start to screw legs into holes by hand.
Use an adjustable wrench or 1" hex-head
socket wrench to finish turning legs until you
reach the ridge with the diamond marking.
4.
Stand dryer up on cardboard
or hardboard.
