Three-wire connection...
POWER SUPPLY CORD
spade
terminals with
upturned ends
This blade connected
to this conductor.
NEUTRAL
3/4" U.L.-listed
strain relief
Three-wire power supply cord must have
three, No.-10 copper wires and match a
three-wire receptacle of NEMA Type
10-30R.
DIRECT WIRE
Preparing the wire:
Three-wire with
ground wire: Bare
wire cut short.
Wire is not used.
Dryer is grounded
through direct
3/4" U.L.-listed
wire cable.
strain relief
to disconnect
box
10-gauge, 3-wire or,
10-gauge, 3-wire with
ground wire (Romex)
Strip 3-1/2 inches of
outer covering from end
of cable. Strip insulation
back 1 inch. If using
3-wire cable with
ground wire, cut bare
wire even with outer
covering.
DIRECT WIRE
OR POWER SUPPLY CORD
Three-wire power supply cord must have
three, No.-10 copper wires and match a
three-wire receptacle of NEMA Type 10-
30R.
Direct wire power supply cable must be
prepared as shown in "Preparing the wire"
of the three-wire connection direct-wire
steps above.
If codes permit and a separate ground
wire is used, it is recommended that a
qualified electrician determine that the
ground path is adequate.
Panel E
Where local codes permit
connecting cabinet-ground conductor to neutral wire:
4.
Loosen or remove center terminal
block screw.
5.
Connect the neutral wire (white or
center) of power supply cord to the
center, silver-colored terminal screw of
ring
terminals
the terminal block. Tighten screw.
6.
Connect the other wires to outer
terminal block screws. Tighten screws.
NEUTRAL
(white or center)
7.
Tighten strain relief screws.
8.
Insert tab of terminal block cover into
slot of dryer rear panel. Secure cover with
hold-down screw.
Where local codes permit
connecting cabinet-ground conductor to neutral wire:
4.
Loosen or remove center terminal
block screw.
5.
Place the hooked end of the neutral
wire (white or center) of power supply
cable under the center screw of the
1" of wires
terminal block (hook facing right).
stripped of
Squeeze hooked end together. Tighten
insulation
screw.
NEUTRAL wire
6.
Place the hooked ends of the other
(white or center)
power supply cable wires under the outer
terminal block screws (hook facing right).
Squeeze hooked ends together. Tighten
screws.
3-1/2"
7.
Tighten strain relief screws.
8.
Insert tab of terminal block cover into
slot of dryer rear panel. Secure cover with
Shape ends
hold-down screw.
of wires
into a
hook.
Where local codes Do Not permit
connecting cabinet-ground conductor to neutral wire:
4.
Remove center terminal block screw.
5.
Remove the appliance harness ground
wire (green with yellow stripes) from the
external ground connector screw.
Connect appliance harness ground wire
and the neutral wire (white or center) of
the power supply cord/cable under the
center, silver-colored terminal block screw.
Tighten screw.
6.
Connect the other wires to outer
terminal block screws. Tighten screws.
7.
Tighten strain relief screws.
8.
Insert tab of terminal block cover into
slot of dryer rear panel. Secure cover with
hold-down screw.
Three-wire receptacle
9.
After reattaching the terminal cover,
connect a separate copper ground wire from
the external ground connector screw to an
adequate ground.
