- Page 1 YS600 NO BARK COLLAR Owner's Manual Please read this manual thoroughly before operating the YS600.
- Page 2 Dogtra product or other property. PRODUCT SAFETY Training Methods Dogtra products may be used with a variety of training methods. However, each dog may have a different reaction to training methods and to Dogtra products. Closely observe your dog when determining the right training method to use with your Dogtra product.
- Page 3 Consult your physician or medical device maker before using your medical device with a Dogtra product. If you think that your Dogtra product is interfering with your pacemaker, defibrillator, or other medical device, stop using the Dogtra product.
- Page 4 UNAUTHORIZED USE Your Dogtra product should be used only in a humane manner to train and educate your dog. Dogtra products are not intended for use in any other manner nor are they intended for use with other animals or with humans.
-
Page 5: Table Of Contents
OVERVIEW ............... USING THE ON/OFF & STIMULATION DIAL ..... LED INDICATOR .............. OPERATING MODES ............PERSISTENT BARK INDICATOR ........TESTING THE YS600 ............CHARGING THE BATTERY ..........RECEIVER FITTING ............MAINTENANCE ............... TROUBLESHOOTING GUIDE ........WARRANTY AND REPAIR INFORMATION .... -
Page 6: At A Glance
AT A GLANCE YS600 Battery Owner's No Bark Collar Charger Manual MAIN FEATURES • Ultra-Compact Receiver • 2-Hour Rapid Charge Batteries • Persistent Bark Indicator • 10 Intensity Levels • High Performance Pager • Accelerometer Bark Sensor • Enhanced Contact Points •... -
Page 7: Overview
OVERVIEW Contact Points Battery Charging Sensor Receptacle & Rubber Plug On/Off & LED Indicator Stimulation Dial Light Collar Strap... -
Page 8: Using The On/Off & Stimulation Dial
10 (highest). Each stimulation level begins with a vibration and is followed by the stimulation. - Set the dial to “T” to test the YS600. See Testing the YS600 on page 11 to check if your unit is working properly. -
Page 9: Led Indicator
4 seconds afterwards. If your dog does not bark for over 30 seconds, the LED indicator will turn off and the YS600 will go into a sleep mode to conserve battery life. It will reactivate when your dog barks and a vibration/correction needs to be made. -
Page 10: Persistent Bark Indicator
PERSISTENT BARK INDICATOR The Persistent Bark Indicator activates when the unit is turned off and there has been excessive barking. 1. Without excessive barking: – The LED will glow red for 2 seconds when the unit is turned off. 2. With excessive barking: –... -
Page 11: Testing The Ys600
TESTING THE YS600 1. Turn the dial to “T”. The LED indicator will blink once every 4 seconds. 2. Use the cap end of a ballpoint pen and scratch between the contact points. The unit is working properly when it vibrates twice. -
Page 12: Charging The Battery
NOTE 2: The unit has a partial charge when it leaves the Dogtra facility. Upon receipt of the system, be sure to give it a full 2-hour initial charge before the first use away from any flammable substances. - Page 13 Follow the steps below to charge your system: 1. Open the rubber plug on the battery charging receptacle and plug in the charging cable. 2. Plug the charger into a 120 volt wall outlet or, if using the auto charger, plug into a cigarette lighter for lithium polymer batteries.
-
Page 14: Receiver Fitting
If the receiver is too loose, the contact will not be consistent and cause the corrections to be inconsistent. Dogtra uses medical grade stainless steel contact points and anti-microbial plastic to protect the dog’s skin. - Page 15 Attention! Leaving the receiver in the same location on the dog’s neck for an extended period of time can cause skin irritation due to the sensitivity from the contact points. If the dog is to wear the receiver for long periods, occasionally reposition the receiver every few hours so that the contact points are moved to a different location on the dog’s neck and remove the...
-
Page 16: Maintenance
Storage Maintenance The YS600 should be fully charged before storing for extended periods. While in storage, the unit should be given a full charge once a month and before the first use. -
Page 17: Troubleshooting Guide
(response may be very subtle). 2. My YS600 is not holding a charge. – The batteries might not be charged properly, or the charger, splitter, and the charging port may not be functioning properly. - Page 18 If the dog is in salt-water, be sure to rinse the receiver and charging port with clean water. – If the above does not resolve your issues, contact Dogtra customer service at info@dogtra.com or (888) 811-9111. 3. My dog has skin irritation.
-
Page 19: Warranty And Repair Information
(1) year from the date of purchase (“Warranty”). The Warranty covers the cost of repair (parts and labor) or replacement (if repair is not feasible) of a defective Dogtra product during said one-year period. For such repaired or replaced products, the remaining portion of the original warranty period, or ninety (90) days, whichever is longer, shall apply. - Page 20 No dealer of Dogtra products, nor any employee or agent of Dogtra, is authorized to make any additions, changes, or extensions to the Warranty. Dogtra, at its sole discretion and at any time, reserves the right to modify the Warranty.
- Page 21 You are responsible for shipping, including cost, of your product to Dogtra for warranty service. Dogtra will handle shipping, including cost, of the repaired or replaced product back to customers in the USA. Dogtra will not be responsible for shipping, including cost and/or applicable taxes or fees, for products sent to Canada.
