Chip Errata
MPC8308 Chip Errata
This document details all known silicon errata for the MPC8308. The following table provides a revision history for
this document.
Revision
Date
5
09/2015
4
07/2013
3
05/2012
2
12/2011
1
11/2011
0
07/2010
© 2015 Freescale Semiconductor, Inc.
Table 1. Document Revision History
Added the following errata:
• eSDHC A-005055 and A-009204
• IEEE1588 A-007734
• PCIe PEX5
• USB A-003845
Added IEEE 1588_19 to Table 3, Summary of Silicon Errata and Applicable Revision.
Modified eTSEC69.
Renamed eTSEC-A002 to A-006502 and modified the write-up.
Renamed "PEX" heading to "PCIe".
Re-ordered the USB errata numerically.
Renamed USB38 to USB erratum A-003817
Added the following errata:
• USB errata: A-003837, A-003827, A-003829
• eSDHC erratum: A-004577
Removed erratum DDR20
• In Table 2, added silicon revision 1.1 SVR and PVR information.
• In Table 3, added silicon revision 1.1 column.
• In Table 3, updated the projected solution for the following errata: IEEE1588-A001,
PCIe- A002, and A-003985.
• Added eLBC-A002
• Removed eLBC1, eLBC2, eTSEC29, IEEE1588_8, USB21
• Added USB-A005, USB-A007, CPU-A022, PCIe-A002, A-003985
• Removed SPI6
• Updated USB-A001
Initial release
Significant Changes
MPC8308CE
Rev. 5, 09/2015
