INSTALLATION, OPERATION
June 05, 2015
P/N
07610-002-23-32
U
& SERVICE MANUAL
INSTALLATION MANUAL FOR EXPORT UNITS
SERVICE MANUAL FOR DOMESTIC UNITS
ELECTRICALLY HEATED MODELS:
TEMPSTAR HH
TEMPSTAR HH NB
TEMPSTAR HH LT
TEMPSTAR HH VENTLESS
STEAM HEATED MODELS:
TEMPSTAR HH S
TEMPSTAR
SERIES
®
Upright Door Dishmachines
Jackson WWS, Inc.
P.O. Box 1060
Barbourville, KY USA
1.888.800.5672
www.jacksonwws.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TEMPSTAR Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jackson TEMPSTAR Series

Summary of Contents for Jackson TEMPSTAR Series

  • Page 1 SERVICE MANUAL FOR DOMESTIC UNITS ELECTRICALLY HEATED MODELS: TEMPSTAR HH TEMPSTAR HH NB TEMPSTAR HH LT TEMPSTAR HH VENTLESS STEAM HEATED MODELS: TEMPSTAR HH S Jackson WWS, Inc. P.O. Box 1060 Barbourville, KY USA June 05, 2015 1.888.800.5672 07610-002-23-32 www.jacksonwws.com...
  • Page 3 To register your product go to www.jacksonwws.com or call 1-888-800-5672. Failure to register your product will void the warranty. REPLACEMENT PARTS WARRANTY Jackson replacement parts are warranted for a period of 90 days from date of installation or 180 days from the date of shipment from the factory, whichever occurs first.
  • Page 4 Added hi-limit thermostat set point instructions. 01-10-13 8252 Updated schematic and control box to reflect rotary switch. QOF NDB- 03-07-13 Updated Jackson logo and company name. Updated warranty page. 03-24-14 Removed "Stop" page. Converted manual from Quark to InDesign. 04-16-14 8291 Changed pages 22, 25, 28 &...
  • Page 5 TEMPSTAR HH S Steam heated, high temp, hot water sanitizing, door-type dishmachine Model: Jackson WWS, INC provides technical support for all of the dishmachines detailed in this manual. We strongly recommend that you refer to this manual before making Serial No.: a call to our technical support staff.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS SPECIFICATIONS Operating Capacities ........................2 Electrical Requirements ........................ 3 Dimensions Tempstar/Tempstar LT/Tempstar NB (Top Mounted Control Box) ......4 Table Dimensions .......................... 7 INSTALLATION & OPERATION Installation Instructions ........................8 Electrical Installation Instructions ....................9 Ventless Heat Recovery Mounting ....................11 Operating Instructions .........................
  • Page 7 TABLE OF CONTENTS SCHEMATICS Solid State (Top Mount Control Box) 208-230V, 50/60Hz, Single/Three Phase ......60 Tempstar HH (Universal Timer) 208-230V, 50/60Hz, Single/Three Phase ........61 Solid State (Top Mount Control Box) 460V, 60Hz, Three Phase ..........62 Tempstar HH (Universal Timer) 460V, 60Hz, Three Phase ............63 Tempstar HH S (Universal Timer) 208-230V, 50/60Hz, Single/Three Phase ......

  • Page 8: Specifications Operating Capacities

    SPECIFICATIONS OPERATING CAPACITIES OPERATING CAPACITY: WATER REQUIREMENTS: Selection A Racks per Hour Tempstar HH & Tempstar HH Ventless: Dishes per Hour 1325 Glasses per Hour 1325 Wash Temperature (minimum) (°F) Wash Temperature (minimum) (°C) Selection B Rinse Temperature (minimum) (°F) Rinse Temperature (minimum) (°C) Racks per Hour Inlet Water Temperature:...

  • Page 9: Electrical Requirements

    SPECIFICATIONS ELECTRICAL REQUIREMENTS NOTE: Typical Electrical Circuit is based upon (1) 125% of the full amperage load of the machine and (2) typical fixedtrip circuit breaker sizes as listed in the NEC 2002 Edition. Local codes may require more stringent protection than what is displayed here.

  • Page 10: Dimensions Tempstar/Tempstar Lt/Tempstar Nb (Top Mounted Control Box)

    SPECIFICATIONS DIMENSIONS (TOP MOUNT CONTROL BOX) LEGEND A - Drain 1 1/2" IPS B - Water Inlet 3/4" IPS C - Electrical Connection 4 [102mm] All vertical dimensions are +/- 1/2" due to adjustable bullet feet. 3 [76mm] 4 [102mm] 25 [637mm] 17 [432mm] 25 1/4 [641mm]...
  • Page 11 SPECIFICATIONS DIMENSIONS (SIDE MOUNT CONTROL BOX) LEGEND 4 [101mm] A - DRAIN 1 1/2" IPS B - WATER INLET 3/4" IPS C - ELECTRICAL CONNECTION All dimensions are in inches. All vertical dimensions are +/- 1/2" due to adjustable 4 [102mm] bullet feet.
  • Page 12 SPECIFICATIONS DIMENSIONS (LEFT SIDE CONTROL BOX) LEGEND A - Drain 1 1/2” B - Water Inlet 3/4” C - Electrical Connection 4 [102mm] All vertical dimensions are +/- 1/2” due to adjustable bullet feet. 15 1/4 [388mm] 3 [76mm] 4 [102mm] 25 [637mm] 4 [102mm] 1 [25mm]...
  • Page 13 B) WATER INLET C) ELECTRICAL CONNECTIONS All vertical dimensions are ± 1/2" due to adjustable bullet feet SPECIFICATIONS DIMENSIONS (VENTLESS HEAT RECOVERY) (639mm 101mm) LEGEND A) DRAIN 1 88 (223 B) WATER INLET C) ELECTRICAL CONNECTIONS (79mm) All vertical dimensions are ± 1/2" due to adjustable bullet feet 3 (76mm) (134mm)
  • Page 14 SPECIFICATIONS TABLE DIMENSIONS NOTE: Please remove the front dress panel from the dishmachine if mounting dishmachine for a LETTER DIM (IN) DIM (CM) corner installation and attaching side tables. Corner installation will trap panel making it difficult to 4” (MIN) 10.2 CM (MIN) remove.

  • Page 15: Installation & Operation Installation Instructions

    INSTALLATION & OPERATION INSTALLATION INSTRUCTIONS Jackson WWS Inc. provides technical support for all of the dishmachines detailed in this manual and recommends that service personnel have this manual on hand when calling technical support staff. Technical support is available from 8:00 a.m.
  • Page 16 INSTALLATION & OPERATION INSTALLATION INSTRUCTIONS WATER SUPPLY CONNECTION: Read the section entitled “PLUMBING THE DISHMACHINE” before proceeding. Install the water supply line (3/4” pipe size minimum, 1/2" pipe size minimum for LT) to the dishmachine line strainer using cop- per pipe. It is recommended that a water shut-off valve be installed in the water line between the main supply and the ma- chine to allow access for service.

  • Page 17: Ventless Heat Recovery Mounting

    INSTALLATION & OPERATION VENTLESS HEAT RECOVERY MOUNTING INSTRUCTIONS Due to shipping constraints the Tempstar High Hood is shipped dissembled, you should receive two pieces. Heat Recovery Unit Base Unit The heat recovery unit Fully Assembled Unit box is located inside the dishmachine shipping box.
  • Page 18 INSTALLATION & OPERATION VENTLESS HEAT RECOVERY MOUNTING INSTRUCTIONS Locate and remove the four 1/4-20 bolts using a 7/16 wrench. These are located in top left and right corner of the unit. Lift the heat recovery unit up and over the lower air inlet, then align and slide unit onto the lower air inlet.
  • Page 19 INSTALLATION & OPERATION VENTLESS HEAT RECOVERY MOUNTING INSTRUCTIONS Connect pressure gauge with a 9/16 wrench. Connect the two hoses using an adustable wrench. The hoses are cut to length and will only reach their intended connection point. A. Connect the Gauge B.
  • Page 20 INSTALLATION & OPERATION VENTLESS HEAT RECOVERY MOUNTING INSTRUCTIONS Locate the wire connectors at the top of the unit and connect the white and black wires from the base unit. Slide wire into the hole and push the lever down Tidy up the wires and lock them in place with the P-Clamp on the top of the unit. P-Clamp Now you have a fully assembled unit.

  • Page 21: Operating Instructions

    INSTALLATION & OPERATION OPERATING INSTRUCTIONS PREPARATION: Before proceeding with the start-up of the unit, verify the following: • The pan strainer and pump suction strainer are clean and in place. • The overflow tube and o-ring are installed. • The wash and rinse arms are screwed securely into place, rotate freely and that their endcaps are tight. POWER UP: To energize the unit, turn on the power at the service breaker.
  • Page 22 INSTALLATION & OPERATION OPERATING INSTRUCTIONS STEAM FLOW: Secure steam flow to the machine in accordance with applicable codes and procedures. Steam flow must be secured prior to cleaning the inside of the machine. SHUTDOWN AND CLEANING: At the end of the workday, close the doors. When the unit completes the cycle, turn the power switch to the OFF position and open the door.
  • Page 23 INSTALLATION & OPERATION DETERGENT CONTROL DETERGENT CONTROL: Detergent usage and water hardness are two factors that contribute greatly to how efficiently this dishmachine will operate. Using detergent in the proper amount can become a source of substantial savings. A qualified water treatment specialist can relate what is needed for maximum efficiency from the detergent. 1.

  • Page 24: False Panel Installation

    INSTALLATION & OPERATION FALSE PANEL INSTRUCTIONS Rack rail removed and repositioned for a corner operation. False panel positioned in unit 1. Remove the rack assembly from the dishmachine. 2. The false panel will mount inside of the dishmachine. 3. Position the panel in the dishmachine on the side to be closed. 4.

  • Page 25: Preventative Maintenance

    PREVENTATIVE MAINTENANCE Jackson highly recommends that any maintenance and repairs not specifically discussed in this manual should be performed by QUALIFIED SERVICE PERSONNEL ONLY (see qualified service agencies in the back of this manual). Performing maintenance on your dishmachine may void your warranty if it is still in effect. By following the operating and cleaning instructions in this manual, users should get the most efficient results from the dishmachine.

  • Page 26: Troubleshooting

    TROUBLESHOOTING PROBLEM POSSIBLE CAUSE REMEDY Dishmachine runs Machine is in delime mode. Change operation mode from DELIME to NORMAL position. continuously in the wash cycle. Wash cycle delay timer is faulty. During the wash cycle, the cam timer will move for the first 30 seconds of the wash cycle.
  • Page 27 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE REMEDY Wash water is not Faulty wash heater. Check element for continuity; if open, replace heater. reaching required temperature. Misadjusted/faulty thermostat(s). Verify operation and setting of thermostats; replace if necessary. Wash thermometer is defective. Replace thermometer. Doors will not close Improper spring tension.

  • Page 28: Parts

    PARTS TOP MOUNTED CONTROL BOX ASSEMBLY...
  • Page 29 PARTS TOP MOUNTED CONTROL BOX ASSEMBLY (CONTINUED)
  • Page 30 PARTS TOP MOUNTED CONTROL BOX ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Control Box Weldment 05700-003-30-14 Timer Bracket 05700-003-02-08 Lock Nut 6-32 05310-373-03-00 Heater Contactor 05945-109-01-69 Terminal Block 05940-011-48-27 Lock Nut 10-24 05310-373-01-00 Contactor, Wash Motor 05945-002-74-20 Relay 05945-111-47-51 Relay (415V, 3PH, 5 Wire Only) 05945-111-89-75 Light, Green 05945-111-44-43...
  • Page 31 PARTS TOP MOUNTED CONTROL BOX ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Fuse Holder, 6 Pole 05920-002-42-13 Screw, 6-32 x 3/8" with Ext. Tooth Washer 05305-002-25-91 Decal, Dispenser Connection 09905-003-34-09 Timer, Universal 05945-003-33-09 Timer, Universal Fused (Alternate) 05945-003-75-23 Locknut, 10-32 05310-373-02-00 Screw 10-32 x 1"...

  • Page 32: Side Mounted Control Box Assembly (Universal Timer)

    PARTS SIDE MOUNT UNIVERSAL TIMER CONTROL BOX ASSEMBLY...
  • Page 33 PARTS SIDE MOUNT UNIVERSAL TIMER CONTROL BOX ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Bracket, Electrical Box Mounting 05700-002-18-48 Locknut, 1/4"-20 S/S Hex with Nylon Insert 05310-374-01-00 Washer, 1/4"-20 I.D. S/S 05311-174-01-00 Control Box Weldment, Right Hand 05700-002-06-48 Control Box Weldment, Left Hand 05700-002-23-08 Contactor, 4 Pole, 220V, 1 Phase 05945-109-01-69...
  • Page 34 PARTS SIDE MOUNT CONTROL BOX ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Cover, Control Box Weldment 05700-002-06-52 Cover, Control Box Weldment (not shown) (LT) 05700-004-22-50 Bolt, 10-32 x 1/2" Slotted Truss 05305-173-04-00 Switch, Rotary Selector - Not on LT 05930-003-97-61 Switch, Operation 05930-301-53-00 Decal, Control Box Cover 09905-003-97-39...

  • Page 35: Side Mounted Control Box Assembly (Mechanical Timer)

    PARTS SIDE MOUNT MECHANICAL TIMER CONTROL BOX ITEM DESCRIPTION PART NUMBER Contactor, 4 Pole, 220V, 1 Phase 05945-109-01-69 No Booster, Steam Models and LT Liquid Level Control 06680-200-08-21 Decal, 120°F Wash/Rinse (not shown) (LT only) 09905-002-82-46 Relay, 240V, 50/60Hz, Top Mount 05945-002-47-74 Timer, Cam/Mechanical 05945-303-31-00...

  • Page 36: Hood Assembly

    PARTS HOOD ASSEMBLY...
  • Page 37 PARTS HOOD ASSEMBLY ITEM DESCRIPTION PART NUMBER Hood Weldment 05700-003-05-67 Hood Support Assembly 05700-004-13-45 Left Back Inner Door Guide 05700-031-76-34 Right Back Outer Door Guide 05700-031-76-32 Right Back Inner Door Guide 05700-031-76-35 Left Back Outer Door Guide 05700-031-76-33 Locknut, 1/4-20 Hex w/Nylon Insert 05310-374-01-00 Washer, S/S 1/4-20 I.D.

  • Page 38: Cantilever Arm/Door Assemblies

    PARTS CANTILEVER ARM/DOOR ASSEMBLIES ITEM DESCRIPTION PART NUMBER Cantilever Arm 05700-004-14-29 Sleeve, Cantilever Arm 05700-000-85-69 Screw, 1/4"-20 x 1 1/2" Long Hex Head 05305-274-23-00 Washer, 1/4" I.D. S/S 05311-174-01-00 Locknut, 1/4"-20 S/S Low Profile with Nylon Insert 05310-374-02-00 Plug, Cantilever 05340-011-35-00 Connecting Link 05700-021-92-45...
  • Page 39 PARTS CANTILEVER ARM/DOOR ASSEMBLIES ITEM DESCRIPTION PART NUMBER Bolt, Cantilever Hanger Eye 3/8"-16 05306-956-05-00 Washer, Impeller 05311-176-02-00 Nut, 3/8"-16 S/S Hex 05310-276-01-00 Door, Upper, Left & Right Assemblies (not shown) 05700-002-01-30 Door, Upper, Left & Right Weldment 05700-002-29-59 Glide, Upper Door 05700-002-00-83 Door, Lower, Right Assembly (not shown) 05700-002-01-33...

  • Page 40: Tub Assembly

    PARTS TUB ASSEMBLY 10, 11 Solid State Thermostat 14, 11 31, 30 22 23 27, 28 W-BRACKET, MOTOR MOUNT INNER 05700-004-13-09 F-BRACKET, MOTOR MOUNT OUTER 05700-004-13-08 LOCKNUT, 1/4-20 05310-374-01-00 BOLT, 1/4-20 X 1/2" 05305-274-02-00 WASHER, 1/4" I.D.X 3/4" O.D. 05311-011-76-30...
  • Page 41 PARTS TUB ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Tub Weldment 05700-002-12-59 Rack Assembly 05700-002-01-00 Bulk Head Plug 04730-609-05-00 See Page Entitled “Wash Motors” Gasket 05700-111-35-03 O-ring 05330-400-05-00 Bolt, Hex 3/8”-16 x 1 1/4" Long 05305-276-10-00 Lower Wash Manifold Weldment 05700-031-46-00 Suction Strain Weldment 05700-001-22-23 Suction Strain Bracket...
  • Page 42 PARTS TUB ASSEMBLY (CONTINUED) ITEM DESCRIPTION PART NUMBER Cover, Wash Heater 05700-031-47-57 Decal, Warning-Disconnect Power 09905-100-75-93 Decal, High Limit 09905-011-84-32 Thermostat Bracket 05700-011-81-64 Wash Heater Gasket 05330-011-47-79 Thermostat, Regulating 05930-510-02-79 Kit, Wash Thermostat Replacement (Includes: thermostat, brass fitting, 2 jumper wires & instruc- 06401-003-18-22 tions) Thermostat, High Limit...

  • Page 43: Steam Tub Assembly

    PARTS STEAM TUB ASSEMBLY 10, 11 14, 11, 15 Solid State Thermostat 22, 23 27, 28 W-BRACKET, MOTOR MOUNT INNER 05700-004-13-09 F-BRACKET, MOTOR MOUNT OUTER 05700-004-13-08 * Represents an item not shown. LOCKNUT, 1/4-20 Nut, 1/4”-20 Serrated Nut 05310-374-01-00 Bracket, Motor Support Weldment BOLT,...
  • Page 44 PARTS PARTS STEAM TUB ASSEMBLY (CONTINUED) See page entitled “Wash Motors” Gasket 05700-111-35-03 O-ring 05330-400-05-00 Bolt, Hex 3/8”-16 x 1 1/4" Long 05305-276-10-00 Lower Wash Manifold Weldment 05700-031-46-00 Suction Strain Weldment 05700-001-22-23 Suction Strain Bracket 05700-001-22-24 Locknut, 1/4"-20 with Nylon Insert 05310-374-02-00 Strainer Weldment 05700-021-50-07...

  • Page 45: Frame Assembly

    PARTS PARTS FRAME ASSEMBLY Cover, Front Panel 05700-002-01-42 Frame Weldment 05700-002-03-49 Frame Weldment, 415V 05700-002-62-41 Frame Weldment 05700-004-22-56 Bullet Foot 05340-108-02-06 Bullet Foot 05340-002-14-55 Flange Feet 05340-002-01-15...

  • Page 46: Rinse Tank Assembly

    PARTS RINSE TANK ASSEMBLY COMPLETE ASSEMBLIES 230V, 14KW 70 ◦ Rise - P/N 06401-004-19-57 240V, 12 KW 40 ◦ Rise - P/N 06401-004-19-55 410V, 12KW 40 ◦ Rise - P/N 06401-004-19-56 415V, 12KW 40 ◦ Rise - P/N 06401-004-19-54 SEE PAGE ENTITLED "WASH HEATERS/RINSE HEATERS."...

  • Page 47: Coil Assembly

    PARTS PARTS COIL ASSEMBLY Complete Steam Coil Assembly 05700-002-08-62 Stand C, Steam Coil Support 05700-002-08-52 Steam Coil Weldment 05700-021-41-38 Stand D, Steam Coil Support 05700-002-08-53 Stand B, Steam Coil Support 05700-002-08-51 Stand A, Steam Coil Support 05700-002-08-50 Gasket, Steam Coil 4 per assembly 05700-001-17-86 Washer, Steam Coil...

  • Page 48: Incoming Steam Plumbing Assembly

    PARTS INCOMING STEAM PLUMBING ASSEMBLIES Union, 3/4’’ NPT, Black Iron To order this complete assembly, use part number: 04730-912-01-01 05700-002-01-55 Bushing, Reducing, 3/4’’ to 1/2’’ 04730-911-02-34 Steam Trap, 3/4” NPT F&T 06680-500-02-77 Elbow, 3/4” 90° Street 04730-011-87-37 Nipple, Close, 3/4’’ NPT, Black Iron 04730-907-01-00 To order this complete assembly, use part number: 05700-002-01-60...

  • Page 49: Wash Motor

    Always refer to the diagrams on the motor you are installing. If the schematics have been removed from the motor you are installing, contact Jackson technical support immediately. The Tempstar models covered in this manual come supplied with various heaters, depending on the characteristics of the machine.

  • Page 50: Incoming Plumbing/Outlet Plumbing Assemblies

    PARTS INCOMING & OUTLET PLUMBING ASSEMBLIES INCOMING PLUMBING OUTLET PLUMBING...
  • Page 51 PARTS PARTS INCOMING & OUTLET PLUMBING ASSEMBLIES (CONTINUED) ITEM DESCRIPTION PART NUMBER Water Pressure Regulator, 3/4" NPT 06685-011-58-22 Valve, Ball, 1/4" NPT 04810-011-72-67 Gauge, Pressure, 0-100 PSI 06685-111-88-34 Nipple, Close 3/4" NPT 04730-207-34-00 Tee, Brass, 3/4" NPT x 3/4" NPT x 1/4" NPT 04730-211-04-00 Valve, Solenoid, 3/4"...
  • Page 52 PARTS INCOMING PLUMBING (TEMPSTAR HH NB) ITEM DESCRIPTION PART NUMBER Vacuum Breaker, 3/4" NPT 04820-002-53-77 Elbow, Brass, Street, 3/4" NPT 04730-206-04-34 Nipple, Brass, 3/4" NPT x 3" Long 04730-011-38-29 Union, 3/4" NPT, Brass with O-Ring 05700-002-63-79 Nipple, Close, Brass, 3/4" NPT 04730-207-34-00 Valve, Solenoid, 3/4"...
  • Page 53 PARTS PARTS INCOMING PLUMBING (TEMPSTAR HH LT) ITEM DESCRIPTION PART NUMBER Fittin, Tee, 1/2C X 1/2C x 1/4 Female 04730-411-25-01 Adapter, 1/2 MNPT X CU Male 04730-011-59-53 Strainer, Y 1/2 04730-217-01-10 Vale, Ball Test Cock 1/4" Bronze 04810-011-72-67 Adapter, Male 04730-401-03-01 Gauge, 0-100# Pressure 06685-111-88-34...

  • Page 54: Ventless Heat Recovery Plumbing Assemblies

    OSE, 1/2" ID X 24" LG RED W-PLUMBING, RINSE INJECTOR 05700-004-19-89 05700-004-19-83 A-PLUMBING, OUTLET_W/ HEAT EXC. 05700-004-19-12 05700-004-19-99 OSE, 1/2" ID X 67" LG RED PARTS ITEM (TEMPSTAR) PART NUMBER A-HOSE, 1/2" ID X 24" LG RED 05700-004-19-89 INCOMING PLUMBING (TEMPSTAR HH VENTLESS) A-HOSE, 1/2"...
  • Page 55 PARTS PARTS INCOMING PLUMBING (TEMPSTAR HH VENTLESS) ITEM DESCRIPTION PART NUMBER Bushing, Hex 3/4"M to 1/2" Brass 04730-002-56-27 Nipple, Brass 1/2" X 3" NPT 04730-004-20-10 Elbow, 1/2 NPT 90 Brass 04730-011-42-96 Tee, 1/2 FNPT X 1/2 FNPT 1/4 FNPT 04730-002-22-56 Union, 1/2"...

  • Page 56: Drain Quench Assembly

    PARTS DRAIN QUENCH ASSEMBLY Elbow, 1-1/2” 90 Street 04730-206-32-00 Drain Quench Assembly 06401-002-59-52 Nipple, 1-1/2” NPT 04730-207-40-00 Modified Compression Fitting Lid, Drain Quench 05700-001-16-52 05700-002-67-16 Thermostat 05930-003-13-65 Solenoid Valve Reducer, 1-1/2” x 1/4” 04810-100-09-18 04730-002-55-76 To Dishmachine Drain To Cold Water Supply Tee, 1-1/2”...

  • Page 57: 1/2" Solenoid Valve & 1/2" Npt Vacuum Breaker Repair Parts Kits

    PARTS PARTS 3/4" SOLENOID VALVE & 3/4" VACUUM BREAKER REPAIR PARTS KITS Screw Cap Screw Data Plate Coil & Housing Data Plate Valve Bonnet Spring 06401-003-07-40 Plunger Cap Retainer 06401-003-07-40 O-Ring O-Ring Diaphragm 06401-003-07-42 Retainer Plunger Diaphragm 06401-003-07-42 Components of Repair Kit 06401-003-06-24 Body Screen...

  • Page 58: Wash & Rinse Arm/Manifold Assemblies

    PARTS WASH & RINSE ARM/MANIFOLD ASSEMBLIES 2, 3, 4 9, 18 6, 18 17, 8 2, 3, 19...
  • Page 59 PARTS PARTS WASH & RINSE ARM/MANIFOLD ASSEMBLIES (CONTINUED) ITEM DESCRIPTION PART NUMBER Upper Manifold 05700-031-34-82 Nut, 3/8"-16 S/S Hex 05310-276-01-00 Lockwasher, 3/8" 05311-276-01-00 Bolt, Hex 3/8"-16 x 7/8" Long 05306-011-36-95 O-Ring 05330-111-35-15 Positioning Bracket, Manifold Tube 05700-011-34-63 Tube, Wash Manifold 05700-031-92-58 Gasket, Manifold 05700-111-35-03...

  • Page 60: Transformer Mounting Box Components

    PARTS 460 VOLT MACHINE TRANSFORMER MOUNTING BOX...

  • Page 61: Exhaust Fan Control

    PARTS PARTS EXHAUST FAN CONTROL OPTION...

  • Page 62: Ventless Heat Recovery Assembly

    PARTS TEMPSTAR HH VENTLESS HEAT REVOCERY SYSTEM ASSEMBLY...
  • Page 63 PARTS PARTS TEMPSTAR HH VENTLESS HEAT REVOCERY SYSTEM ASSEMBLY ITEM WasherDESCRIPTION PART NUMBER Coil, Heat Exchanger 04420-004-19-61 Inlet, Cold Water 05700-004-19-01 Ring, Water Inlet 05700-004-19-24 Plate, Fan Mounting 05700-004-18-07 Upper Shroud 05700-004-18-06 Exhaust Box 05700-004-18-04 Gasket, Heat Exchanger 05330-004-18-22 Gauge 06680-011-86-42 Coil Box Back 05700-004-18-03...

  • Page 64: Door Interlock

    PARTS TEMPSTAR HH VENTLESS DOOR INTERLOCK ITEM DESCRIPTION PART NUMBER Guide Block, Door Lock 09330-004-22-72 F-Cover, Door Lock Mounting 05700-004-22-80 W-Rod, Interlock Weldment 05700-004-23-15 Soleniod, Horizontal 1" Push 04820-004-24-11 Spring, Comp. 05935-004-24-10 W-Base, Door Interlock Box 05700-004-24-25 Screw 3/8 Pan Head 05305-171-02-00 Washer, Flat #10 05311-173-02-00...
  • Page 65 PARTS PARTS SAFETY DOOR INTERLOCK/DOOR OVERRIDE INSTRUCTIONS Other Safety Door Interlock (SDI) components (not shown): Pipe Clamp (found on the side of the machine) 05700-000-35-05 Solenoid, Electrical Interlock Option 04810-100-61-33 Relay 05945-111-47-51 Safety Door Interlock Box Cover Safety Door Interlock Box Bottom 05700-001-21-27 05700-001-21-26 Latch access hole...

  • Page 66: Solid State (Top Mount Control Box) 208-230V, 50/60Hz, Single/Three Phase

    ELECTRICAL SCHEMATICS SOLID STATE TEMPSTAR HH (TOP MOUNT CONTROLS), 208-230V, 60HZ, 1 & 3 PHASE...

  • Page 67: Tempstar Hh (Universal Timer) 208-230V, 50/60Hz, Single/Three Phase

    ELECTRICAL SCHEMATICS TEMPSTAR HH (UNIVERSAL TIMER), 208-230V, 60HZ, 1 & 3 PHASE...

  • Page 68: Solid State (Top Mount Control Box) 460V, 60Hz, Three Phase

    ELECTRICAL SCHEMATICS SOLID STATE TEMPSTAR HH (TOP MOUNT W/CYCLE SWITCHES), 460V, 60HZ, 3 PHASE...

  • Page 69: Tempstar Hh (Universal Timer) 460V, 60Hz, Three Phase

    ELECTRICAL SCHEMATICS TEMPSTAR HH (UNIVERSAL TIMER), 460V, 60HZ, 3 PHASE...

  • Page 70: Tempstar Hh S (Universal Timer) 208-230V, 50/60Hz, Single/Three Phase

    ELECTRICAL SCHEMATICS TEMPSTAR HH S (UNIVERSAL TIMER), 208-230V, 60HZ, 1 & 3 PHASE...

  • Page 71: Tempstar Hh 208-230V, 50/60Hz, Single/Three Phase

    ELECTRICAL SCHEMATICS TEMPSTAR HH 208-230V, 60HZ, 1 & 3 PHASE...

  • Page 72: Tempstar Hh 460V, 60Hz, Three Phase

    ELECTRICAL SCHEMATICS TEMPSTAR HH, 460V, 60HZ, 3 PHASE...

  • Page 73: Tempstar Hh S 208V-230V, 60Hz, Single/Three Phase

    ELECTRICAL SCHEMATICS TEMPSTAR HH S, 208-230V, 60HZ, 1 & 3 PHASE...
  • Page 74 ELECTRICAL SCHEMATICS TEMPSTAR HH, NB 208V-230V, 50/60HZ, 1 PHASE...

  • Page 75: Solid State Tempstar Hh, Nb/Lt 208-230V, 50/60Hz Single Phase

    ELECTRICAL SCHEMATICS TEMPSTAR HH, NB/LT 208V-230V, 50/60HZ, 1 PHASE...

  • Page 76: Sdi Option

    ELECTRICAL SCHEMATICS: OPTIONS SDI OPTION...

  • Page 77: Exhaust Fan Hookup/Drain Quench Options

    ELECTRICAL SCHEMATICS: OPTIONS EXHAUST FAN HOOKUP/DRAIN QUENCH OPTIONS...
  • Page 78 Tempstar HH Series Installation, Operation & Technical Manual 07610-002-23-32 Issued: 09-14-07...
