DEMO MANUAL DC1732
PARTS LIST
ITEM QTY REFERENCE
Required Circuit Components
1 1 T1
2 6 C2, C3, C4, C11, C12, C13
3 1 C7
4 2 C5, C14
5 8 C33, C34, C35, C37 to C41
6 3 C21, C30, C31
7 1 C8
8 8 C6, C9, C23 to C27, C36
9 2 C1, C10
10 0 C20, C28, C32
11 0 D1
12 1 J9
13 2 J6, J8
14 10 J1 to J5, J10,
J11, J12, J13, J14
15 1 J15
16 1 J7
17 0 L4
18 1 R69
19 3 R70, R71, R72
20 3 L1, L2, L3
21 11 R2, R4, R5, R6, R9, R10, R11,
R61 to R64
22 1 R3
23 8 R39 to R46
24 1 R7
25 4 R65, R66, R67, R68
26 4 R1, R31, R32, R33
27 0 R12 to R15, R17, R21, R23 to R26,
R48 to R56, R60
28 14 C22, C29, R16, R18, R22, R29,
R34, R36, R37, R38, R47, R57,
R58, R59
29 2 R19, R20
30 5 R8, R27, R28, R30, R35
31 5 TP1, TP2, TP3, TP4, TP5
32 1 U1
6
PART DESCRIPTION
BALUN, 1:1, SMT, SM-22
CAP , X5R, 1µF , 10V, 10%, 0603
CAP , X5R, 2.2µF , 10V, 10%, 0603
CAP , TANT, 100µF , 10V, 10%, C 6032
CAP , X7R, 0.01µF , 16V, 10%, 0603
CAP , X7R, 0.01µF , 16V, 10%, 0402
CAP , X5R, 1µF , 10V, 10%, 0402
CAP , X5R, 0.1µF , 10V, 10%, 0402
CAP , X5R, 4.7µF , 10V, 10%, 0603
CAP , DNI, 0402
DIODE, DNI, SOT-23
CONNECTOR, FMC MEZZAININE
CONN, SMA 50Ω PC MOUNT, FEMALE
HEADER, 3 × 1, 2mm
HEADER, 2 × 25, 2mm
HEADER, 2 × 7, 2mm
IND, DNI, 0603
RES, 0Ω JUMPER, 0603
RES, 0Ω JUMPER, 0805
IND, BEAD, 1206
RES, 1k, 1%, 1/16W, 0402
RES, 31.6k, 1%, 1/16W, 0402
RES, 33k, 1%, 1/16, 0402
RES, 1.74k, 1%, 1/16W, 0402
RES, 33.0, 1%, 1/16W, 0402
RES, 10k, 1%, 1/16, 0402
RES, DNI, 0402
RES, 0Ω JUMPER, 0402
RES, 49.9, 1%, 1/16, 0402
RES, 100, 1%, 1/16, 0402
TURRET, 0.093
IC, VREG, 1.8V, 500MA, SO8
MANUFACTURER/PART NUMBER
MACOM MABA-007159-000000
AVX 0603ZD105KAT
AVX 0603ZD225KAT
VISHAY 293D107X9010C2TE3
AVX 0603YC103KAT
AVX 0402YC103KAT
AVX 0402ZD105KAT
AVX 0402ZD104KAT
AVX 0603ZD475KAT
OPT
OPT
SAMTEC ASP-134606-01
AMPHENOL 132134
SAMTEC TMM-103-02-L-S
SAMTEC SQT-125-01-F-D
MOLEX 87831-1421
OPT
VISHAY CRCW06030000Z0ED
VISHAY CRCW08050000Z0ED
MURATA BL31PG330SN1L
PANASONIC ERJ-2RKF1001X
PANASONIC ERJ-2RKF3162X
PANASONIC ERJ-2RKF3302X
PANASONIC ERJ-2RKF1741X
PANASONIC ERJ-2RKF33R0X
PANASONIC ERJ-2RKF1002X
OPT
VISHAY CRCW04020000Z0ED
PANASONIC ERJ-2RKF49R9X
PANASONIC ERJ-2RKF1000X
MILL MAX 2501-2-00-80-00-00-07-0
LINEAR TECHNOLOGY LT1763CS8-1.8
dc1732f
