Specifications

Find Quality Products Online at:
General Specifications
Display
Functions
Polarity
Current sensor
Overload
DCA zero adjust
Display rate
Battery
Operating temperature
Operating Humidity
Power consumption
Weight
Dimensions
Jaw opening
Standards
Range Specifications
DC Current Resolution
40A 10mA
400A (0 to 150A) 100mA
400A (150 to 200A) 100mA
400A (200 to 400A) 100mA
AC Current Resolution
4A (0 to 500mA) 1mA
4A (500mA to 4A) 1mA
40A 10mA
100A (0 to 100A) 100mA
400A (100 to 200A) 100mA
400A (200 to 400A) 100mA
Frequency (Hz) Resolution
40Hz to 250Hz 0.01 to 0.1Hz
250Hz to 10kHz 0.1 to 1Hz
GlobalTestSupply
www.
3-3/4 Digit LCD with 40 segment bargraph
Current (ACA, DCA) and Frequency (Hz)
"-" indicates negative polarity (positive polarity assumed)
Hall effect
Display indicates "1___" or "-1___"
One-touch zero key (also used as a Relative function)
2 readings/second (20 readings/second for bargraph)
Two 1.5V AA batteries
0 0 0 0
4 F to 122 F (-10 C to 50 C)
< 85% RH
10mA DC approx.
6.2 oz. (190g) including battery
7.2 x 2.5 x 1.4" (183 x 63.6 x 35.6mm) (H x W x D)
0.9" (23mm)
IEC 1010 Category III 300V, Category II 600V
Accuracy (of rdg + digits)
±(1.0% + 2d)
±(1.0% + 2d)
±(2.2% + 2d)
±(4.0% + 2d)
50/60Hz 40Hz - 1kHz
±(1.5% + 7d) ±(2.0% + 7d)
±(1.5% + 3d) ±(2.0% + 4d)
±(1.5% + 3d) ±(2.0% + 4d)
±(1.5% + 3d) ±(2.0% + 4d)
±(2.2% + 3d) ±(2.5% + 4d)
±(4.0% + 3d) ±(5.0% + 4d)
Accuracy Sensitivity
±(0.5% + 2d) 3.0A
±(0.5% + 2d) 0.3A
6
Overload Protect
400A DC
400A DC
400A DC
400A DC
Overload Protect
400A AC
400A AC
400A AC
500A AC
500A AC
500A AC
Overload Protect
500A AC
500A AC
380947-EN-V3.1-3/12
