Pressure Switch (S)
A compact integrated pressure switch can be easily installed and
facilitates the pressure detection of the line.
Specifications
Fluid
Proof pressure
Maximum operating pressure
Set pressure range (off)
Differential
Ambient and fluid temperature
Switch characteristics
Contact point configuration
Maximum contact point capacity
Operating voltage: AC, DC
Maximum operating current
Cross Interface (C)
M5 x 0.8, 1/8, 1/4, 3/8, 1/2
Pipings are possible in all 4 directions.
IN/OUT ports are not machined for threads. Contact
SMC if threaded (machined) ports are required.
Cautions in Mounting
• When mounting a cross interface directly on the IN side of the
lubricator, be sure to use a series AKM check valve between the
lubricator and cross interface.
• Factory mounting of a cross interface on the AC model is
available as a special order.
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Pressure switch
Air
1.0MPa
0.7MPa
0.1 to 0.4MPa
0.08MPa
–5 to 60°C (with no freezing)
1a
2VA(AC), 2W(DC)
100V or less
AC, DC12V to 24V: 50mA
AC, DC48V: 40mA
AC, DC100V: 20mA
Cross interface
Attachment Specifications
JIS symbol
Model
IS1000M-20
IS1000M-30
IS1000M-40
IS1000M-50
IS1000M-60
Note) Separate interfaces are required for modular unit.
IS1000M
Pressure switch
20
For AC20
30
For AC25, AC30
40
For AC40-02 to 04
50
For AC40-06
60
For AC50, AC55, AC60
F
Model Port size
Y14-M5
Y24- 01
Y24- 02
Y34- 01
Y34- 02
Y44- 02
Y44- 03
Y54- 03
Y54- 04
Notes) • „ in the model numbers indicates a thread type. No indication is necessary for Rc;
however, indicate N for NPT, and F for G.
• If threaded ports are required, they are available as a special order. Contact SMC.
Series
15
23
A D
A B C D Applicable model
11 76 66 28 AC20
13 86 72 30 AC25 , AC30
15 95 77 36 AC40
17 99 79 44 AC40 -06
22 92.5 68.5 53 AC50 , AC55 , AC60
How to Order
30
Accessories
X201
Body size
X202
X207
X215
This product is for overseas use
only
Measurement Law. (The SI unit
type is provided for use in Japan.)
Center of
F.R.L. body
F
E
E: 4-Rc
A
F: Without thread
A B C D
M5 23 16 14 25 AC10
1/8
40 40 22 40 AC20
1/4
1/8
28
49 43 48 AC25 , AC30
1/4
1/4
60 48 36 54 AC40
3/8
3/8
72 62 40 62 AC40 -06
1/2
AC
Center of
F.R.L. body
Lead wire length: 3m
Regulating pressure
range: 0.1 to 0.6MPa
MPa/PSI Dual scale
Lead wire length: 3m;
Regulating pressure
range: 0.1 to 0.6MPa
according to the new
Port size
E
E
E
D
Applicable model
