Mechanical Style Pressure Switch
Series
Long service life:
5 million cycles
IS1000-01
Arrow.com.
Downloaded from
Specifications
Fluid
Proof pressure
Max. operating pressure
Regulating pressure range (at OFF point)
Hysteresis
Error of scale
Repeatability
Contacts
Wiring specifications
Fluid
Ambient and fluid temperature
Port size
Weight
Switch Characteristics
IS1000-01-X202
Max. contact capacity
Voltage
Max. operating current
Impact resistance
Electrical Circuit
Up to 100 VAC/DC
IS1000
Model
IS1000
01 S
Port size
1
01
R
/
8
1
N01
NPT
/
8
For details about certified products
conforming to international standards,
visit us at www.smcworld.com.
IS1000-01
Air/Inert gas
1.0 MPa
0.7 MPa
0.1 to 0.4 MPa
0.08 MPa or less
±0.05 MPa
±0.05 MPa
1a
Grommet, Lead wire length 0.5 m (Standard)
Air
–5 to 60°C (No freezing)
R 1/8
74 g
AC 2 VA, 2 W DC
24 VAC/DC or less
48 VAC/DC
50 mA
40 mA
30 G
Operating Pressure Range
ON pressure
0.5
0.4
0.3
0.2
0.1
0
0.1
Set pressure scale (MPa)
How to Order
Seal
Option
Nil
None
X201
S
With seal
X202
X215
ZSE„
ISE„
PSE
Z
SE3
I
PS
Z
1
SE
I
2
ZSP
ISA2
IS„
ZSM
PF2„
IF„
Data
100 VAC/DC
20 mA
OFF pressure
0.2
0.3
0.4
Lead wire length 3 m
Regulating pressure range
0.1 to 0.6 MPa
Lead wire length 3 m
Regulating pressure range
0.1 to 0.6 MPa
16-9-1
