4.3.4 Setup menu

Setup Menu
1 Calibration
1 Auto calibration
2 End point cal.
3 Start PST ref
4 Start FST ref
5 Start SOT ref
2 Identification
3 Live
4 Event log
5 Scheduler
6 HART
7 Modbus
8 Display

4.4 Bluetooth

Bluetooth can be used to control the valve system though the IDC or to download signatures to a
mobile device.
Range:
IDC24-AF with external antenna: 20 meters
IDC24-F with external antenna: 20 meters
IDC24-A with internal antenna: 2 meters
IDC24-AF with internal antenna and glass lid: 2 meters
When connecting to a IDC with internal antenna, the connecting devices must be right in front of
the IDC.
After the Tag no. is changed the device must be power cycled to update the Bluetooth name.

4.5 Internal memory

The device is available in two models, standard or with local storage on microSD card.
A signature contains all test data and a curve of the test.

4.5.1 Standard

The last 10 events are stored in memory.
The IDC will store test data from the last performed test of each type
•
one PST
•
one PST reference
•
one FST
•
one FST reference
•
one SOT
•
one SOT reference
