4.3 Buttons - menus

Four menus can be accessed from the main screen by pressing each of the buttons or using
MTControl.
The F model only has one button. Pressing it for 3 seconds will initiate the auto calibration. The
tests and auto calibration can be aborted by pressing the button for one second.

4.3.1 Test menu

Test Menu
1 Start PST
2 Start FST
3 Start SOT

4.3.2 Diagnostic menu

Diagnostic Menu
1 PST
Date
Time
Last test result
Start pressure
React
Breakaway time
Breakaway pressure
PST time
Press
PrsTi
RetTi
FilTi
Total time
Max. travel
Min. pressure
Enable errors
Enable warnings
2 FST
Date
Time
Last test result
Start pressure
React
Breakaway time
Breakaway pressure
Breakaway pos.
limit
FST time
DePrs
PrsTi
RetTi
FilTi
Total time
Enable errors
Enable warnings
3 SOT
Date
Time
Val Controls A/S • Limfjordsvej 3 • DK-6715 Esbjerg N • Tel. +45 7547 0600
DID-UM-002
Revision: 10
Description
Start a partial stroke test
Start a full stroke test
Start a solenoid test
Description
View the reference and latest partial stroke test values and limits
Date the test was performed
Time the test was performed
Result of the latest test
Start pressure
SOV reaction time
Breakaway time
Breakaway pressure
PST time
PST pressure
PST pressurising time
PST return time
Actuator fill time
PST total time
PST maximum travel
PST minimum pressure
Enable errors
Enable warnings
View the reference and latest full stroke test values and limits
Date the test was performed
Time the test was performed
Result of the latest test
Start pressure
SOV reaction time
Breakaway time
Breakaway pressure
Breakaway position error limit
FST time
FST depressurising time
FST pressurising time
FST return time
Actuator fill time
FST total time
Enable errors
Enable warnings
View the reference and latest solenoid valve test values and limits
Date the test was performed
Time the test was performed
