- Use of your own aids e.g. push stick, rulers, etc.
is not permitted.
- Before commencing work, check that the guard
and splinter guard can move freely and are rest-
ing on the table.
- To prevent the saw blade from overheating or
the plastic from melting, set the correct speed
for the cutting material and do not use excess
pressure when cutting.
- When cutting metal, switch on the saw using a
residual current circuit breaker.
- Check the plug and the cable regularly and
should either become damaged, have them
replaced by an authorised after-sales service
workshop.
4.4
Emission levels
Typically, the noise levels that are determined in
accordance with EN 61029 are as follows:
Sound pressure level
Sound power level
Measuring uncertainty allowance
Wear ear protection!
- The specified noise emission levels have been
measured in accordance with the standard test-
ing method and can be used to compare power
tools.
- The specified noise emission levels can also be
used for making preliminary estimates regard-
ing noise load.
CAUTION
The noise emissions during actual use
of the power tool can differ from the
declared values depending on the ways
in which the tool is used especially what
kind of workpiece is processed.
-
Identify safety measures to protect
the operator that are based on an estima-
tion of exposure in the actual conditions
of use (taking account of all parts of the
operating cycle such as the times when
the tool is switched off and when it is run-
ning idle in addition to the trigger time).
4.5
Other risks
In spite of compliance with all relevant design
regulations, dangers may still present themselves
when the machine is operated, e.g.:
- Workpiece parts being thrown off,
- Parts of damaged tools being thrown off,
- Noise emissions,
- Wood dust emissions.
5
- When unpacking the tool, remove all transport
inserts.
- Ensure that the floor around the machine is
level, in good condition and free of loose objects
(e.g. chips and offcuts).
5.1
The machine can be set up with or without un-
folded legs (fig. 1 and 2).
To unfold the legs, loosen the four rotary knobs
[1-6] all the way. Tighten the four rotary knobs
again once the legs are unfolded.
If the machine wobbles, the length of one leg can
be adjusted by turning the end cap [1-7] until the
machine stands securely.
5.2
5.2a
- Remove the yellow safety sticker [12-10].
L
= 87 dB(A)
PA
L
= 101 dB(A)
- Set the saw to maximum cutting depth and the
WA
mitre to 0°.
K = 3 dB
- Pull the wedge [12-8] into the upper position.
- Take hold of the guard and completely unscrew
the screw [12-5].
- Place the guard on the riving knife. In doing this,
guide the lengthwise pin that is located in the
guard into the groove [12-9] on the wedge and
push the screw [12-5] into the hole in the riving
knife and tighten it.
5.2b
Push the handle of the preset profile setting rail
into the zero position (fig. 15). Tighten the screw
[3-6] (fig. 3) and attach it to the table.
5.3
- Click the saw unit into place in the zero position.
- Remove all attachments from your saw and wind
up the cable on the cable holder.
- Fold up the legs if necessary.
5.3a
the machine's leg ends are equipped with trans-
port rollers. Take hold of the power tool by the
handle area [2-6] and pull it to the desired place.
5.4
The machine can be used as a table saw or as a
circular trimming saw.
25
Set-up, operation
Setting up the machine
Prior to initial operation
Installing the guard (fig. 12)
Installing the preset profile setting rail
Transport
When transporting the power tool, hold
it by the handle areas on the sides [2-6].
Never take hold of or transport the power
tool by the protective cover.
For transport over short distances, two of
Scope of application
English
