4K HDR 4 Input Matrix Switcher
with 2 Scaling Outputs
EXP-MX-0402-H2
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the installation
process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest firmware, document version,
additional documentation, and configuration tools.
• Read through the
Wiring and Connections
before creating or choosing premade cables.
Basic Wiring Diagram
4K HDR Source
DC 5V
4K HDR Source
4K HDR Source
Copyright © 2019 WyreStorm Technologies |
EXP-MX-0402-H2 Quickstart Guide | 191011
section for important guidelines
4K HDR Source
HDMI
HDMI
HDMI
HDMI
wyrestorm.com
In The Box
1x EXP-MX-0402-H2 Matrix
1x 5V DC 1A power supply
1x 3.5mm 3-pin Terminal Block
1x Remote Control Handset (CR2025 Battery not Included)
2x Mounting Brackets
Audio Video Receiver
Analog Audio
Digital Audio
HDMI
1080p Display
1 of 4
Quickstart Guide
5.1 Audio System
Control System
RS-232
EXP-MX-0402-H2
HDMI
KEY
HDR Display
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
HDMI
Digital Audio
Analog Audio
Power
Control
support@wyrestorm.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wyrestorm ESSENTIALS EXP-MX-0402-H2
Summary of Contents for Wyrestorm ESSENTIALS EXP-MX-0402-H2
- Page 1 4K HDR 4 Input Matrix Switcher with 2 Scaling Outputs Quickstart Guide EXP-MX-0402-H2 WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation process. In The Box IMPORTANT! Installation Requirements 1x EXP-MX-0402-H2 Matrix •...
- Page 2 Wiring and Connections WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in it’s entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
- Page 3 • If transmitting 3D or 4K, verify that the HDMI cables used are 3D or 4K rated. Troubleshooting Tips: • WyreStorm recommends using a cable tester or connecting the cable to other devices to verify functionality. Copyright © 2019 WyreStorm Technologies | wyrestorm.com...
- Page 4 Regulatory Safety and Emission CE | FCC | RoHS Note: WyreStorm reserves the right to change product specification, appearance or dimensions of this product at any time without prior notice. Copyright © 2019 WyreStorm Technologies | wyrestorm.com UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
