C CLI C
OMMON
The following are common CLI commands and tips for getting started with the CLI.
■ Entering a question mark (?) shows contextual help and options. For example, entering ? at
the prompt will show all commands available from that prompt.
■ To view interface statistics, enter show interfaces <interface type> <interface number>.
■ To view the current configuration, enter show running-config.
■ To view all the IP Addresses currently configured, enter show ip interfaces brief.
■ To view the AOS version, serial number, and other information, enter show version.
■ To save the current configuration, enter write.
P
OWER OVER
The NetVanta 3148 PoE router (P/N 17003148F11) and the NetVanta 4148 PoE router
(P/N 17004148F11) are Power over Ethernet (PoE) routers. PoE routers provide the ability to
detect attached powered devices (PDs) and deliver 48 VDC to the PD via exiting Ethernet
cabling. The NetVanta 3148 and 4148 PoE Series are fully compliant with the IEEE 802.03af and
IEEE 802.03at PoE+ standards. by default, the PoE routers discover and provide power to IEEE-
compliant PDs.
To disable PoE, use the power inline never command in the CLI. To disable power detection and
supply from the GUI, navigate to the Power over Ethernet page and select OFF in the Enable
column for a specific port (e.g., giga-swx 0/1).
M C
ANUALLY
g
NOTE
The configuration parameters used in the examples outlined in this document are for instructional
purposes only. Please replace all underlined entries (example) with your specific parameters to
configure your application.This step is unnecessary if the unit's IP address has been configured
automatically using DHCP.
The following steps create an IP address and subnet mask for the GIG 0/1 Gigabit Ethernet port.
If you are not sure what IP address to assign, please contact your network administrator.
1. At the # prompt, enter config terminal.
2. At the (config)# prompt, enter interface gigabit-eth 0/1 to access the configuration
parameters for the GIG 0/1 port located on the front of the unit.
3. Enter ip address 10.10.10.1 255.255.255.0 to assign an IP address to the GIG 0/1 port
using a 24-bit subnet mask.
4. Enter no shutdown to activate the interface to pass data.
5. Enter exit to exit the Ethernet interface commands and return to the Global Configuration
mode.
6. Enter ip route 0.0.0.0 0.0.0.0 10.10.10.254 to add a default route to the route table. 0.0.0.0
is the default route and the default subnet mask, and 10.10.10.254 is the next-hop IP
address to which the AOS router should send all of its traffic. You will need to enter the
proper route, subnet mask, and gateway for your network. This information is typically
provided by a service provider or local network administrator.
7. Enter do write to save the current configuration.
617004148F1-13B
OMMANDS
E
THERNET
ONFIGURING THE
U ' IP A
NIT S DDRESS
3
