FORCED AIR
OVENS
MICROPROCESSOR
CONTROLLED
MODELS:
TFO-1, TFO-3, TFO-5, TFO-10, TFO-28
INSTALLATION AND OPERATIONAL MANUAL
REV 01.07

Advertisement

loading
Need help?

Need help?

Do you have a question about the TFO-1 and is the answer not in the manual?

Questions and answers

Related Manuals for Cascade TEK TFO-1

Summary of Contents for Cascade TEK TFO-1

  • Page 1 FORCED AIR OVENS MICROPROCESSOR CONTROLLED MODELS: TFO-1, TFO-3, TFO-5, TFO-10, TFO-28 INSTALLATION AND OPERATIONAL MANUAL REV 01.07...
  • Page 2 These units are not intended for hazardous or household locations or use. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124...
  • Page 3 Supply nameplate data, including model number and serial number. Accessories: Verify that all of the equipment indicated on the packing slip is included with the unit. Carefully check all packaging before discarding. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250...
  • Page 4 Indicates “Over Temperature Safety” Indicates “Earth Ground” Indicates “Potential Shock Hazard” behind partition Indicates “Unit should be recycled” (Not disposed of in land-fill) 2.10 Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com...
  • Page 5 With the unit standing upright, turn the leveling feet counterclockwise to raise level. If the unit must be moved, turn the leveling feet in all the way to prevent damage. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124...
  • Page 6 To burn in, turn the Over-Temperature Safety to maximum and set the digital display to 200°C. Run a minimum of one (1) hour until smoke dissipates. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250...
  • Page 7 This oven is NOT designed for use in Class I, II, or III locations as defined by the National Electrical Code. This oven is not intended, nor can it be used, as a patient connected device. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124...
  • Page 8 The light will come on when the Safety Thermostat has been activated and taken control of the oven temperature. Under normal operating conditions this pilot lamp should never be on. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124...
  • Page 9 If you want moderate ventilation in the oven, open the vent at the top. Maximum flow thru the vent(s) will slightly increase heat up and recovery time. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com...
  • Page 10 Note: The set point will not change even if the power is turned on and off. Please refer to the enclosed Controller manual for complete instructions. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250...
  • Page 11 F O R C E D A I R O V E N M A N U A L Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com REV 01.08...
  • Page 12 F O R C E D A I R O V E N M A N U A L Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com REV 01.08...
  • Page 13 Stabilize. Turn the OTP safety thermostat to a temperature lower than that on the main temperature controller. Make sure the OTP light comes on, and that oven temperature decreases. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124...
  • Page 14 3/ Is the Safety Thermostat set high enough? – for diagnostics, should be fully clockwise with the OTP light never on. 4/ Has the fuse/circuit breaker blown? Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250...
  • Page 15 This can be a normal condition when operating temperature varies widely. For maximum accuracy, calibration should be done at or as close to the set point temperature. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250...
  • Page 16 1/ Adjust hinge blocks or twist the door. 2/ Confirm unit has not been damaged / body out of square. 3/ Check physical condition of gasket for tears or punctures. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124...
  • Page 17 3/ Protect open samples from areas of maximum air current, e.g., inlet air ducts. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com...
  • Page 18 FTLR OUTPUT HYS1 ENT3 ENT3 Note: The PID Settings for the TFO Ovens are set by running the auto-tune feature at 150C. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com...
  • Page 19 Section 9 PARTS LIST Please note – Part Numbers are subject to change. Please confirm description and model number with your order. PART NO. DESCRIPTION PART NO. DESCRIPTION TFO-1 TFO-3 1800516 Power Cord 1800516 Power Cord 9570762 Element Assy. 9570537 Element Assy.
  • Page 20 This warranty is in lieu of and excludes all other warranties or obligations, either express or implied. Manufacturer expressly disclaims all implied warranties, including without limitation, the warranties of merchantability and fitness for a particular purpose. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com...
  • Page 21 OPTIONAL EQUIPMENT 11.1 COBEX CHART RECORDER INSTALLATION: TFO-10 & TFO-28 The following installation procedure is for installing a 6” Cobex Chart Recorder in a Cascade TEK TFO-10 or TFO-28 Forced Air Oven: Uncrate oven. Do not connect power. Locate Chart recorder cut-out at the right corner of the instrument panel.
  • Page 22 Press “Mode” button until “Event 3” displays. Press the “UP” arrow to turn ON the Power Exhaust within in your profile. Press the “DOWN” arrow within the profile to turn the power exhaust off. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124...
  • Page 23 Press “Mode” button until “Event 3” displays. Press the “UP” arrow to turn on the GN2 Purge Flow Meter in your profile. Press the “DOWN” arrow to turn off. GN2 Inlet Connection Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com...
  • Page 24 O V E N M A N U A L Section 12 UNIT SPECIFICATIONS Please refer to the unit data plate for its individual specifications. TFO-1, 1.6-cu/ft forced air oven Interior Dimensions: 13” W x 14 ¾” H x 14¼” D Exterior Dimensions: 22 ½”...
  • Page 25 Port: 2½ - access port in back Vent: 1 air intake vent and 1 exhaust vent on top Weight (uncrated): 455 lbs. Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com...
  • Page 26 F O R C E D A I R O V E N M A N U A L ASTM E 145-68 & ASTM 1292-94 Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com...
  • Page 27 F O R C E D A I R O V E N M A N U A L Section 13 SCHEMATICS WIRE DIAGRAM : TFO-1 & TFO-3 Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com...
  • Page 28 F O R C E D A I R O V E N M A N U A L WIRE DIAGRAM: TFO-5 Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com...
  • Page 29 F O R C E D A I R O V E N M A N U A L WIRE DIAGRAM: TFO-10 Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com...
  • Page 30 F O R C E D A I R O V E N M A N U A L WIRE DIAGRAM: TFO-28 Cascade TEK 5245-A NE Elam Young Parkway Hilllsboro Oregon 97124 Toll Free 888-835-9250 503-648-1818 FAX 503-648-1798 info@cascadetek.com www.cascadetek.com...
