RUN AN AUTOMATED SENSOR TEST

Select a Sensor PreCheck
1
home page with which to connect. The Sensor PreCheck
icon will be grey until selected, and will turn green after
selection. If multiple sensors are attached for testing,
a pop‑up window will appear to determine if each
connected sensor is the same or different model(s).
Select the appropriate response for the connected
sensor(s) to continue.
1
RJG, INC. SENSOR PRECHECK | QUICK START GUIDE
icon from the application
3
Enter the Mold Number
2
Begin Automated Test
3
Progress Bar will indicate the test progress. Wait for the
test to complete.
The automated test complete page
5
alerts, warnings, and the number of sensors that passed
the test. Select a sensor
6
information, including Location, Cavity Name, Pin Size,
Sensitivity, Sensor Model, and Sensor Serial Number.
Complete the testing by running a force test (page
4).
2
in the provided field. Select
to test the sensor(s). The
will indicate any
to enter the sensor
5
6
4
4
3
