RJG CoPilot AP 32C Hardware Installation Quick Start Manual

CoPilot™ Hardware Installation Quick Start Guide—Electric Machines
STANDARD EQUIPMENT QTY
a
AP4.0—
Application Processor
PS‑AP50W‑12V—
AP4.0 Power Supply/
b
Cable
c
Touch Screen Computer
Touch Screen Cables—
One HDMI,
d
One USB
LE‑R‑50—
Lynx 50" Stroke/Velocity
e
Encoder
CE‑LX5‑4M‑F90—
Lynx Four‑Meter
f
90°Cable
g
CE‑LX5‑2M— Lynx Two‑Meter Cable
h
CE‑LX5‑4M—
Lynx Four‑Meter Cable
i
J‑LX1—
Lynx Single Feed‑Through
j
ID7‑M‑SEQ—
Lynx Sequence Module
C‑ID7‑M‑3M—
Shielded Cable for
k
ID7‑M‑SEQ
OR2‑M—
Lynx Relay Module OR
l
OA1‑M‑V—Lynx Analog Output Module
C‑OR2‑M‑3M—
Shielded Cables for
m
OR2‑M
n
IA1‑M‑V—
Lynx Analog Input Module
C‑IA1‑M‑3M—
Shielded Cable for
o
IA1‑M‑V
p
J‑LX5— Lynx Five‑Port Junction Box
OPTIONAL EQUIPMENT QTY
u
L‑PX—
Lynx Proximity Switch
Item not shown.
1
For standard installation; use of L‑PX requires a quantity of 3.
2
For standard installation; use of L‑PX requires a quantity of 2.
3
4 Only used if mold closed signal is not available from the ID7‑M‑SEQ sequence module.
5 OA1‑M‑V used for control (V→P) if OR2‑M cannot be utilized.
Refer to the CoPilot™ Hardware Installation and Setup Guide for more information—download online at https://www.rjginc.com.
1
1
1
1
1
1
3
1 2
1
3
1
1
1
1
1
5
2
1,5
Installation
1
Read and follow all instructions, notes, and cautions before
installing hardware components. Contact RJG, Inc. Customer
1
1
Support for any questions regarding installation.
1
CAUTION Always disconnect, lock out, and tag out all
1 power sources before making electrical connections. Failure to
1,4
comply will result in injury or death to personnel and damage or
destruction of equipment.
e
n l j g i
f p
h d a
All rights reserved. © RJG, Inc. 2018
