MANUAL STRAIN GAGE SENSOR FORCE TEST

The manual strain gage sensor force test
Basic and Device Force.
press on the sensor(s) being tested in order for the
Sensor PreCheck to evaluate if the sensor is detecting
force.
NOTE The application will time out if no signal is
received from the sensor within a specified length of time;
be ready to apply force to the sensor(s).
12
tests for
The operator must physically
1
The manual strain gage sensor force test will display a
1
test in progress
2
No Signal Detected
4
signal is or is not detected.
2
page, then a Signal Detected
3
screen to indicate if a sensor
3
OVERVIEW | RJG, INC. SENSOR PRECHECK
OR
4
