Piezoelectric Sensors - RJG Sensor PreCheck User Manual

PIEZOELECTRIC
SENSORS
NOTE Do not move
the Lynx cable during
piezoelectric sensor
testing, as it will create
false test results.
After running an
automated test, select
one of the following:
• Test Basic and Device
1
Force
• Touch to Begin Force
2
Test
• Force Test All
3
NOTE The appli‑
cation will time out if
no signal is received
from the sensor in
a specified length
of time; be ready to
apply force to the
sensor(s).
Select End Force
4
Test after the Signal
5
Detected screen is
displayed.
The No Signal
6
Detected screen will
be displayed if the
test was unsuccessful.
Refer to PAGE 31 for
troubleshooting.
20
1
2
6
3
5
4
USER TOOLS | RJG, INC. SENSOR PRECHECK
