RJG, INC. SENSOR PRECHECK | USER TOOLS
1
3
6
5
4
5
4
MANUAL SENSOR
FORCE TESTS
STRAIN GAGE SENSORS
After running an
automated test, select
one of the following:
•
Test Basic and Device
1
Force
•
Touch to Begin Force
2
Test
•
Force Test All
3
NOTE The
application will time
out if no signal is
received from the
sensor in a specified
length of time; be
ready to apply force
to the sensor(s).
Select
End Force
4
Test
after the
Signal
5
Detected
screen is
displayed.
The
No Signal
6
Detected
screen will
be displayed if the
test was unsuccessful.
Refer to PAGE 30 for
troubleshooting.
19
