SENSOR TEST REPORTS

Sensor test reports are generated automatically and
stored in the tablet's Device Storage/Downloads folder.
The reports can be viewed while in the Sensor PreCheck
application, or opened or emailed from the tablet's file
directory.
Select the share button
1
after completing sensor testing.
RJG, INC. SENSOR PRECHECK | OVERVIEW
to view a sensor test report
1
Reports detail incomplete
2
warnings, and the number
5
testing. The reports also show if the tested sensor
has passed communication,
6
gage only), zero shift
8
(piezoelectric only), and
successfully. The report will include any entered
sensor information, such as Location, Pin Type, and Pin
Size.
1
5 2
6
8
11
tests, alerts,
3 4
of sensors that passed
gage/wire (strain
7
(strain gage only), drift
9
basic force testing
10
3 4
9
10
7
11
