RUN A MANUAL SENSOR FORCE TEST

Sensor force tests require the operator to physically
press on the sensor(s) being tested in order for the
Sensor PreCheck to evaluate if the sensor is detecting
force.
NOTE The application will time out if no signal is
received from the sensor in a specified length of time; be
ready to apply force to the sensor(s).
2
4
1

STRAIN GAGE SENSORS

After completing an automated test, select
Basic and Device Force
Test to force test a single sensor, OR
force test all sensors.
Select End Force Test
4
screen when the force test is complete.
3
QUICK START GUIDE | RJG, INC. SENSOR PRECHECK
Test
1
OR Touch to Begin Force
2
Force Test All
3
to return to the test results
4
4
to
