Cochlear Mini Mic 2+ Connection Procedures

Remote microphone connection

Remote Microphone Connection Procedures for the Kanso

with Cochlear Mini Mic 2+ as Transmitter

1. Pair the MM2+ to the Kanso (pairing only needs to be done once, unless MM2+ has been paired to another processor)

a. Turn off the Kanso by pressing and holding the button for 5 seconds until the indicator light turns a steady orange, then release the

button.

b. Turn on the MM2+ by pressing the ON/OFF button until the LED turns green, then release the button.

c. With the tip of a ballpoint pen, press the pairing button once. The LED will flash yellow. Within 20 seconds, turn on the Kanso by

pressing and holding the button until the LED turns green, then release the button.

Pairing button

2. The LED on the Kanso will blink blue, which indicates pairing is successful.

3. Activate STREAMING on the Kanso by pressing and holding the Kanso button for 3 seconds until a 3-tune melody is heard by the student

and the LED blinks blue.

Table of Contents

Need help?

Do you have a question about the Mini Mic 2+ and is the answer not in the manual?

Page 1 Remote Microphone Connection Procedures for the Kanso with Cochlear Mini Mic 2+ as Transmitter 1. Pair the MM2+ to the Kanso (pairing only needs to be done once, unless MM2+ has been paired to another processor) a. Turn off the Kanso by pressing and holding the button for 5 seconds until the indicator light turns a steady orange, then release the button.
Page 2 Alternatively, STREAMING can be activated with the Remote Assistant. From the home screen, press the right arrow key until the STREAM screen is displayed. Press the down arrow key until “1 Mini Mic” is highlighted. Press OK. The LED on the Kanso will start blinking blue and the MM icon will appear on the home screen of the Remote Assistant.
Page 3 1. Teacher to turn off the MM2+ by pressing the ON/OFF button until the LED turns red, then release the button. 2. Student to toggle Kanso out of streaming by pressing the Kanso button once quickly. The LED will blink green once. Alternatively, streaming can be turned off with the Remote Assistant by one quick press on the Telecoil button or by selecting OFF on the Stream screen.
