Summary of Contents for Cochlear True Wireless Mini Microphone 2
- Page 1 POCKET GUIDE COCHLEAR TRUE WIRELESS ™ ™ MINI MICROPHONE 2 & 2 Mini Microphone 2 Mini Microphone 2+...
- Page 2 Welcome to Cochlear ™ True Wireless Technology. ™ No Strings Attached. Index Overview 4. Getting Started Product Diagram Pairing 8. Using 11. Care & Maintenance Visit us online for helpful tips, how-to videos and more: www.Cochlear.com/US/N6wireless Recipients.MyCochlear.com...
- Page 3 The Cochlear Wireless Mini Microphone ™ 2 & 2+ are designed to allow you to hear better over a distance and in noisy listening situations, such as: In meetings When traveling by car, bus or train Dining at a restaurant...
-
Page 4: Getting Started
Getting Started Charging the battery Plug one end of the included micro USB charging cable into the Mini Microphone and the other into a computer, or into a power outlet via the supplied adapter. When the LED indicator on top of the Mini Microphone turns green with a red blink every 2 seconds charging is complete. -
Page 5: Product Diagram
Product Diagram Status indicator (LED) ON/OFF button Volume up control Mute button Clip Volume down control Micro-USB connector Micro-USB connector for charging (2+) for charging (2) Line input (2+) FM connector (2+) - Page 6 Pairing Follow the four steps below to pair your Nucleus 6 Sound Processor to the ® Cochlear Wireless Mini Microphone Switch off your CP900 Series Sound Processor. Remove the Sound Processor from your ear. Disconnect the battery. Press and hold Kanso button until the light is a steady orange.
- Page 7 Press the pairing button on the (A) Mini Microphone 2 or (B) Mini Microphone 2+ once using the tip of a pen or similar object. Pairing button Note: The LED will flash yellow every 2 seconds and the Mini Microphone will now be in pairing mode for 20 seconds.
- Page 8 Using Now that the Cochlear Wireless Mini Microphone is paired you are ready to start streaming. There are several ways to do this. Start streaming using your sound processor Turn on your sound processor and Mini Microphone. Press and hold the upper button on your sound processor for 2 seconds, then release.
- Page 9 To stop streaming. Tap the upper button. Tap the button. Start streaming using your CR210 Remote Control Turn on your sound processor and Mini Microphone. Turn on your CR210 Remote Control. Press and hold the Telecoil button for 2 seconds, then release. Audio will start streaming through the Mini Microphone.
- Page 10 Start streaming using your CR230 Remote Assistant Method 1: Turn on your sound processor and Mini Microphone. Turn on your CR230 Remote Assistant. Press and hold the Telecoil button for 2 seconds, then release. Audio will start streaming through the Mini Microphone. To stop streaming, tap the Telecoil button.
-
Page 11: Care And Maintenance
Care and Maintenance • Clean the Cochlear Mini Microphone using a damp cloth. Never use household cleaning products (washing powder, soap, etc.) or alcohol to clean the device. • When the Cochlear Mini Microphone is not in use, turn it off and store it safely. - Page 12 Cochlear Canada Inc. 2500-120 Adelaide Street West Toronto, ON M5H 1T1 Canada Telephone: 1 416 972 5082 Fax: 1 416 972 5083 ©Cochlear Limited 2016. All rights reserved. Trademarks and registered trademarks are the property of Cochlear Limited. FUN2593 ISS2 OCT16...
