Operation
6.12 Replacing the AC fuse
D
DANGER! Danger of electrocution!
Disconnect the connection cable before you replace the device fuse.
➤ Remove the connection cable.
➤ Pry out the fuse insert (fig. 3 2, page 3) with a screwdriver.
➤ Replace the defective fuse with a new one that has the same rating (T4AL 250 V).
➤ Press back the fuse insert into the housing.
6.13 Replacing the plug fuse (12/24 V)
fig. 7, page 4
➤ Pull the adapter sleeve (4) off of the plug.
➤ Unscrew the screw (5) out of the upper half of the housing (6).
➤ Carefully lift the upper half of the housing off the lower half (1).
➤ Take out the contact pin (3).
➤ Replace the defective fuse (2) with a new one that has the same rating
(T8 A 32 V).
➤ Re-assemble the plug in the reverse order.
I
NOTE – Internal DC fuse
There is an additional DC fuse inside the device (Automotive standard
blade fuse, 10 A). This fuse can only be replaced by an authorised repair
centre.
6.14 Replacing the bulb (CF16, CF26)
➤ Press the switch pin (fig. 8 2, page 4) downwards so that the transparent part
(fig. 8 1, page 4) of the lamp can be removed at the front.
➤ Replace the light bulb.
➤ Press the transparent part of the lamp back into the housing.
