Air Conditioner Features

WARNING
To reduce the risk of re, electric shock, or
injury to persons, read the IMPORTANT
SAFETY INSTRUCTIONS before operating
this appliance.
CAUTION
Please always wait 3 minutes when turning unit
o then on again, and when changing from cool
to fan and back to cool. This prevents
compressor from overheating & possible circuit
breaker tripping.
Air Directional Louvers
Lever
A ir D irec tion
for 05K, 06K
Levers
A ir D irec tion
for 06K, 08K, 10K, 12K, 15K, 18K, 25K,28.5K
The louvers will allow you to direct the air ow Up or Down(on some models) and Left or Right
throughout the room as needed. Pivot horizontal louvers until the desired Up/Down direction is
obtained. Move the Lever(s) from side to side until the desired Left/Right direction is obtained.
Fresh Air Vent Control （on 10-12 K MODELS）
cord.
F ig. A
(VENT CLOSED)
The Fresh Air Vent allows the air conditioner to:
1. Recirculate inside air - Vent Closed (See Fig.A)
2. Draw fresh air into the room- Vent Open (see Fig.B)
3. Exchange air from the room and draws fresh air into the room - Vent and Exhaust Open (see Fig.C)
 Page 28 
The louvers will allow you to direct the air ow Left or Right
throughout the room as needed.
Move the Levers from side to side until the desired Left/Right
direction is obtained.
Levers
A ir D irec tion
F ig. B
(VENT OPEN)
To begin operating the air conditioner,
follow these steps:
1. Set the thermostat to the highest number
(coldest or cooler setting).
2. Set the selector control to the highest COOL
setting.
3. Adjust the louver for comfortable air ow (see
Air Directional Louvers).
4. Once the room has cooled, adjust the
thermostat to the setting you nd most
comfortable.
5. Make sure that the air ow inside and outside
are not obstructed by anything.
F ig. C
(VENT & EXHAUST OPEN)
Levers
A ir D irec tion(4- way)
