Operation Manual (EN)
Original version of the operation manual
Rotary vane pumps
Two-stage
Series CRVpro
CRVpro 48
CRVpro 65
P1700040
2020-06-12
P1700011
2020-06-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WELCH CRVpro Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Gardner Denver WELCH CRVpro Series

  • Page 1 Operation Manual (EN) Original version of the operation manual Rotary vane pumps Two-stage Series CRVpro CRVpro 48 CRVpro 65 P1700040 2020-06-12 P1700011 2020-06-12...
  • Page 2 Fax: +86 21 50396221 manual, including extracts, is not E-Mail: welch.as@gardnerdenver.com allowed without the prior written www.welchvacuum.com permission of Co. Gardner Denver Thomas GmbH. Global Headquarters All rights under the copyright laws are Gardner Denver Thomas GmbH expressly reserved by Co. Gardner Livry-Gargan-Str.
  • Page 3: Table Of Contents

    Contents Contents Important Information ........................1 Meaning of the Warning and Information notes ..............1 General Information ........................ 1 Target Groups ........................2 Intended Use .......................... 2 Use for an Unauthorized Purpose ..................2 Product Standards, Safety Regulations ................. 3 Basic Safety Instructions .........................
  • Page 4 Contents 5.5.3 Change the Voltage Setting ....................19 5.5.4 Motor Protection........................19 Starting-up ........................... 21 Operating Temperature ....................... 21 Oil for Drawing off Oxygen ....................22 Gas Ballast Control ......................22 5.10 Trap installation and maintenance ..................22 5.11 Side Panel Fitting Port ......................23 5.12 Closing down ........................
  • Page 5: Important Information

    Important Information Important Information 1.1 Meaning of the Warning and Information notes Take note of the warning notes which are in the following boxes: CAUTION! / WARNING! Hazard which may lead to serious injuries or material damage. WARNING! Hot surface which may lead to serious injuries or material damage. Information which are only relevant of CE operation are marked in following boxes: ONLY RELEVANT FOR CE (230-240)/(380-420)V;...
  • Page 6: Target Groups

    Important Information Our products are sold worldwide and can therefore be equipped with the typical national plugs and for the various voltages. ONLY RELEVANT FOR CE (230-240)/(380-420)V; (200/346)V / 50HZ OPERATION The rotary vane pump conforms to the following directives: Directive on machinery 2006/42/EC Directive on waste electrical and electronic equipment...
  • Page 7: Product Standards, Safety Regulations

    Important Information 1.6 Product Standards, Safety Regulations ONLY RELEVANT FOR CE (230-240)/(380-420)V; (200/346)V /50HZ OPERATION The rotary vane pump meets the following product standards: Safety of machinery - Electrical equipment of machines - EN 60204-1 Part 1: General requirements Observe the standards and regulations applying in your country when you use the rotary vane pump. P1700040...
  • Page 8: Basic Safety Instructions

    Basic Safety Instructions Basic Safety Instructions IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS 2.1 General Information CAUTION! To reduce the risks of fire or explosion, electrical shock, and the injury to persons, read and understand all instructions included in this manual. Be familiar with the controls and the proper usage of the equipment ...
  • Page 9: Hazardous Substances

    Basic Safety Instructions  External mechanical stresses and vibrations must not be transmitted to the pump. Only use flexible vacuum hoses for connecting Rotary vane pumps.  The pump should not be used to suck up fluids. Lay the exhaust pipe so that it slopes downwards, so allowing condensate to flow out of the pump.
  • Page 10: Description

    Description Description 3.1 Design The CRVpro series vacuum pumps are oil-sealed, two-stage Rotary vane pumps. The drive motor is directly flange-mounted onto the motor cover of the pump holder and the pump shaft and the motor shaft are connected to each other by an elastic coupling. The bearings of the interior pump body are force-fed lubricated sliding bearings.
  • Page 11 Description Followed the scope of delivery for standard model numbers. The scope of delivery for other model numbers is specified in the supply contract. P1700040...
  • Page 12: Function

    Description 3.4 Function 3.4.1 Principles of Vacuum Pump Operation The main purpose of a vacuum pump is to reduce the pressure in a vessel or a closed system. The degree of pressure reduction is dependent upon the requirements of the application and the type of vacuum pump employed.
  • Page 13 Description Two pump stages (fore-stage and high-stage) are arranged in series in order to improve the end pressure and the pumping speed at lower pressures. The intake takes place in the first stage (high- stage), the compression and the outlet in the second stage (fore-stage). Fig.
  • Page 14: Oil Functions

    Description This state of equilibrium is referred to as the ultimate pressure or blank off pressure of the pump and its system. No matter how much additional pumping time is provided, no further reduction in system pressure will be accomplished once ultimate pressure is attained. Intake Anti-suck back Protection When power to the pump is turned off, this device closes automatically, maintaining vacuum in the system being evacuated, and vents the inside of the pump to atmospheric pressure.
  • Page 15 Description When pumping condensable vapours, they may be compressed during the compression phase above the saturated vapour pressure and condense. This causes considerable deterioration in the vacuum pump’s performance:  ultimate pressure is not achieved  corrosion occurs  heavy oil contamination and formation of emulsions CAUTION! Operating with gas ballast increases the operating temperature of the vacuum pump by 5 –...
  • Page 16: Technical Data

    Technical Data Technical Data 4.1 Dimensions Fig. 4 Dimensions (in mm) 4.2 Pumping Speed / Intake Pressure – Diagram Fig. 5 Pumping Speed / Intake Pressure (50Hz) - Diagram CRVpro 48+65 P1700040...
  • Page 17: Device Data

    Technical Data 4.3 Device Data 3487T-xx 3657T-xx Parameter Unit CRVpro 48 CRVpro 65 Free Air Displacement (max. pumping speed) 74.3 (1238.3) - @ 50Hz /h (L/min) 55.7 (928.3) 52.5 (1486.7) - @ 60Hz CFM (L/min) 39.4 (1113.3) Pumping Speed 65.0(1083.3) - @ 50Hz /h (L/min) 48.0(800)
  • Page 18: Lubrication Data

    Technical Data 4.5 Lubrication Data Welch Directorr™ Premium vacuum oil is a triple-distilled hydrocarbon oil using severely hydro treated base stock. The oil is designed to resist breakdown at higher RPMs and operating temperatures of direct-drive vacuum pumps. The hydro treating virtually eliminates aromatics and sulphur to give good resistance to sludge and varnish formation over time in corrosive environments.
  • Page 19: Installation And Operation

    Installation and Operation Installation and Operation 5.1 Unpacking Carefully unpack the rotary vane pump. Keep all paperwork and inspection tags for future reference. Check the pump for:  Transport damage  Conformity with the specifications of the supply contract (model, electrical supply data) ...
  • Page 20: General References

    Installation and Operation 5.4 General References CAUTION! On continuous operation it’s recommended to run the pump below 10mbar maximum vacuum pressure. According to its intended use the capacity of the vacuum pump depends on:  the kind of assembly  accessories ...
  • Page 21: Connection To The Electric Service

    Installation and Operation 5.5.1 Connection to the Electric Service WARNING! Should the user change the electrical connection, for example for fitting into a system, then this may only be performed by an electrical specialist under observance of the accident prevention regulations. ...
  • Page 22: Installation Of The Grounding Plug

    Installation and Operation 5.5.2 Installation of the Grounding Plug ONLY RELEVANT FOR UL ((240-265)/(415-460)V / (200/346)V 60HZ OPERATION This product must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. User should equipped this product with a cord having a grounding wire with an appropriate grounding plug.
  • Page 23: Change The Voltage Setting

    Installation and Operation 5.5.3 Change the Voltage Setting Depending on the order number, pump are customer wired for low voltage (LV/△) 230-240/50Hz, 240- 265/60Hz, 200/50/60Hz or high voltage (HV/Y) 380-420/50Hz, 415-460/ 60Hz, 346/60Hz, the voltage setting can be changed as followed: 1.
  • Page 24 Installation and Operation CAUTION! The motor has PTC inside, the user must integrate the GRB temperature control module into the three phase power station and connect with the motor PTC. Once the PTC sent out temperature rise signal to the power station, then the power station will cut off the power supply and the user should restart the power manually after pump cooling down.
  • Page 25: Starting-Up

    Installation and Operation 5.6 Starting-up Observe the basic safety instructions when using the pump. Before using the pump for the first time, it is recommended to spend a few minutes inspecting the pump and its electrical and vacuum connections. Please notice the information which are listed in chapter 5 Installation and Operation.
  • Page 26: Oil For Drawing Off Oxygen

    Installation and Operation 5.8 Oil for Drawing off Oxygen WARNING! Pump should be not used for oxygen service! Oxygen at atmospheric pressure is exceptionally dangerous! For drawing off oxygen containing mixtures or pure oxygen the following must be taken into consideration: ...
  • Page 27: Side Panel Fitting Port

    Installation and Operation can produce dangerously high pressures. If the trap becomes saturated it should be disconnected from the system, drained and cleaned. An increase in pressure in the vacuum system will normally indicate that the trap has become saturated. To clean the trap, remove the trap from the system, allow the trap to warm up and rinse off the condensate with a suitable solvent in a fume hood.
  • Page 28: Storage

    Installation and Operation WARNING! Take appropriate safety measures in case of having delivered dangerous media! 5.13 Storage The pumps are to be stored in a low-dust, interior room within the temperature range from + 5 to + 40 ° C and at a relative air humidity < 90%. Leave the protective elements on the suction and pressure ports.
  • Page 29: Maintenance And Servicing

    Maintenance and Servicing Maintenance and Servicing Under normal operating conditions the maintenance of the rotary vane pump is limited to:  external cleaning  checking running noises  checking the level and quality of the oil  regular oil changes These maintenance intervals must be specified according to the prevailing operating conditions and adhered to.
  • Page 30: Oil Colour Check

    Maintenance and Servicing Oil fill plug Oil drain plug Lower marking MIN Oil sight glass Upper marking FULL Fig. 11 Oil level control 6.2 Oil Colour Check WARNING! The condition and quality of the pump oil have a substantial effect upon the performance and operational readiness of the vacuum pump! Comparing the colour of a sample of the pump oil with fresh oil provides an indication of the contamination of the pump oil.
  • Page 31: Filling Up With Oil

    Maintenance and Servicing WARNING! Avoid skin contact with the oil! Dispose of the oil in accordance with the valid environmental protection regulations! 6.3.2 Filling up with Oil 1. Switch off the pump, disconnect from the power outlet and from the vacuum system. 2.
  • Page 32: Frequency Of Oil Changes

    Maintenance and Servicing 6.3.4 Frequency of Oil Changes The oil change interval is completely dependent upon the running conditions of temperature, operating pressure, hours of daily operation, and upon the materials pumped. Clean, dry air at pressures below 0.7 mbar (50 mtorr) are the most forgiving conditions. To determine your own oil change interval, visually monitor the pump oil conditions at regular intervals.
  • Page 33: Troubleshooting

    Troubleshooting Troubleshooting Only manufacturing firm and authorized service workshops may work on the pump and their accessories during the warranty period. Remedy Trouble Cause with: Qualified No power supply Check electrical installation electrician Motor defective Exchange Service workshop Coupling defective Repair and/or exchange Vacuum pump Put vacuum pump in a warm...
  • Page 34 Troubleshooting Remedy Trouble Cause with: switched off - Opened gas ballast valve User Close the gas ballast valve possible rise in oil pressure Qualified Cable(s) defective and/or brittle Exchange of the cable(s) electrician P1700040...
  • Page 35: Overview Of Accessories

    Overview of Accessories Overview of Accessories 8.1 Overview and Order Numbers for EMEA, Asia Type Product name Description Order no. OME85/40 Exhaust oil mist filter – with surface treatment for corrosion resistance DN 40 KF 700623 Exhaust Filter Replacement Element for Oil Mist Eliminator OME85/40 DN 40 KF 800165...
  • Page 36: Sorption Trap Adt

    Overview of Spare Parts Type Product name Description Order no. Flexible metal hose, stainless steel 250 mm (9.8”) length welded DN 40 (NW 40) flange 710760 Flexible metal hose, stainless steel 500 mm (19.7”) length welded DN 40 (NW 40) flange 710763 Flexible metal hose, stainless steel 1000 mm (39.4”) length...
  • Page 37: Fastening Kit

    Overview of Spare Parts CAUTION! We are not liable for any damage caused by the installation of any parts not supplied by the manufacturer. 9.1 Fastening Kit The fastening kit contains all the fasten parts which could be replaced during a preventive maintenance or repair.
  • Page 38: Seal Kit

    Overview of Spare Parts 9.2 Seal Kit The seal kit contains all the seals which must be exchanged during a preventive maintenance or repair.  For the Rotary vane pumps CRVpro 48+65 Order no. S3410-99 Description CRVpro 48+65: S3410-99 Item no. Consisting of : Order no.
  • Page 39: Oil Drain Valve Kit

    Overview of Spare Parts 9.4 Oil Drain Valve Kit The oil drain valve kit makes the maintenance of draining the oil easier. Details about draining the oil see 6.3.1.  Oil Drain Valve Kit for CRVpro 48, 65 EMEA Order no. 340011 ...
  • Page 40: Side Panel Fitting Kit

    Overview of Spare Parts Exhaust diaphragm S3484-99 ScrewM5*10 S3485-99 S3482-99 9.6 Side Panel Fitting Kit The side panel fitting kit contains all the parts could be replaced during a preventive maintenance or repair.  For the rotary vane pumps CRVpro 48+65 Order no.
  • Page 41: List Of Spare Parts

    Overview of Spare Parts 9.7 List of Spare Parts Fig. 12 Exploded view CRVpro 48+65 CRVpro 48+65 Item no. Description Order no. Motor ASSY (230-240)/(380-420)V ±5% 50Hz S3486-99 (240-265)/(415-460)V ±5% 60Hz Motor ASSY 200/346V,50HZ,±10% S3487-99 200/346V,60HZ,±10% Pump fan S3412-99 paper washer S3413-99 Coupling Element S3414-99...
  • Page 42 Overview of Spare Parts Order no. Right side overlay S3416-99 Elastic washer8 S3179-99 ScrewM8*35 S3083-99 Foot pad S3008-99 Base S3417-99 3M adhesive tape S3418-99 Felt S3419-99 O-ring S3420-99 Trestle S3421-99 spring S3166-99 Anti-suck back Piston S3165-99 Ring S3422-99 O-ring26X2.65 S3172-99 Oil seal SC 10164 S3019-99 screw M5*14...
  • Page 43 Overview of Spare Parts CRVpro 48+65 Item no. Description Order no. Washer S3436-99 O-ring19.5()x1.6 S3437-99 Bush S3438-99 Oil seal TC 25*45*11 S3439-99 back-up ring S3440-99 Pump Cover S3441-99 ScrewM5*25 S3442-99 Oil Pump Rotor(in) S3443-99 Oil Pump Rotor(out) S3444-99 O-ring75()x2 S3445-99 Gasket S3446-99 Fore CRVpro 48...
  • Page 44 Overview of Spare Parts Order no. O-ring14()*3 S3063-99 Oil drain plug S3062-99 O-ring S3476-99 Glass S3477-99 Oil window S3478-99 O-ring21()x2.65 S3018-99 Oil fill plug S3056-99 Washer S3479-99 Exhaust Port S3480-99 KF40Centre rest S3481-99 S3482-99 holder S3483-99 Exhaust diaphragm S3484-99 Flat washer5 S3120-99 ScrewM5*10 S3485-99...
  • Page 45: Warranty

    Gardner Denver Thomas, Inc. under this warranty is limited to servicing, adjusting, repairing or replacing any unit or component part which in the judgment of Gardner Denver Thomas, Inc. has not been misused, abused or altered in any way causing impaired performance or rendering it inoperative.
  • Page 46: Ec Declaration

    EC Declaration 11 EC Declaration P1700040...
  • Page 47: Global Contact

    Global Contact 12 Global Contact EMEA Gardner Denver Thomas GmbH Am Vogelherd 20 98693 Ilmenau Germany Phone: +49 3677 604-0 Fax: +49 3677 604-131 E-Mail: welch.emea@gardnerdenver.com www.welchvacuum.de America Gardner Denver Thomas Inc. 1601 Feehanville Drive Suite 550 Mt. Prospect, IL 60056...
