• PIR Sensor Installation Angle
When installing the camera, please install the
camera angularly (the angle between the sensor
and the detected object is larger than 10°) for
effective motion detection. If the moving object
approaches the PIR sensor vertically, the sensor
may not detect the motion events.
FYI:
• The PIR sensor's detecting distance: 20ft (in
default)
• The PIR sensor's detecting angle: 120° (H)
• Camera Ideal Viewing
Distance
The ideal viewing distance is 2-10 meters
(7-33ft), which enables you to recognize a
human.
10 English

Charge the Battery

θ
The path of the
moving object
1. Charge the battery when it's
installed to the camera.
θ 10°
Charging indicator:
Entrance
NOTICE: Please note that the solar panel is NOT included in the package. You can buy the solar
panel on Reolink official online store.
!
Reolink Argus 2 or Argus Pro is not designed for 24/7 full capacity running or around-the-clock
live streaming. It's designed to record motion events and remotely view live streaming only when
you need it.
Please learn some useful ways to maximize the battery life in this post:
https://support.reolink.com/hc/en-us/articles/360006991893
2. Charge the battery
separately.
Orange LED: Charging Green LED: Fully charged
Important Safeguards on Rechargeable Battery Use
3. Charge the battery with the
Reolink Solar Panel.
English 11
