Agility Installation - ROHO AGILITY Operation Manual

Wheelchair Compatibility
Cane Sleeve Installation (If Needed)
Warning: Cane Sleeves are required for wheelchair back cane diameters of 3/4 in. to less than 1 in. (2.0 to < 2.5 cm).
See W c c
heelchair ane oMpatiblity
Note: If you need to use Cane Sleeves, perform the following instructions after the AGILITY has been placed onto the wheelchair canes but
before tightening the bolts.
Spread open the Cane
Sleeve and place it on the
wheelchair cane. Slide the
Cane Sleeve down inside the
pivoting band. Repeat for
both sides.

AGILITY Installation

STOP: If the back shell hardware is not yet installed on your AGILITY back shell, see b
Warnings:
- DO NOT install or remove an AGILITY while the individual is
seated in the wheelchair.
- DO NOT adjust the width of an AGILITY while the individual is
seated in the wheelchair.
- After you install or adjust an AGILITY, and before the individual
transfers into the wheelchair, make sure that all hardware
is securely tightened. Refer to the recommended torque
specifications.
Installation Options:
Follow the instructions for i
wheelchair canes have push handles or other equipment
that may interfere with installation.
Otherwise, follow the instructions for i
Loosen the Bolts - Option A and Option B
1) For both sides: Loosen the bolt.
Note: The end of the bolt should
be flush with the adjustment
cylinder.
ROHO AGILITY Back System Fixed Hardware Operation Manual
in p S .
roduct pecificationS
o a if your
nStallation ption
o b.
nStallation ption
For both sides, tighten the bolt with the
Allen wrench as directed in i
nStallation
o a or i o
ption nStallation ption
Note: It may be helpful to position the
opening of the Cane Sleeve toward the
back shell.
S h
ack hell ardWare
Notes:
- The cover should be installed on the back shell before installing
an AGILITY. Refer to the ROHO AGILITY Back System Operation
Manual provided with your AGILITY.
- During installation and removal, provide support to the center
of the back shell to help keep the left (L) and right (R) hardware
even and flush up against the canes.
- Lock the wheelchair wheels before beginning installation.
- An AGILITY installation video is available at ROHO.com.
AGILITY Installation Steps for Option A or Option B:
1. Loosen the Bolts
2. Place the AGILITY On the Wheelchair
3. Tighten the Bolts
4. Complete Attachment
5. Height Adjustment
6. Seat Depth and Angle Adjustment
IMPORTANT! The bolt
should NOT disengage from
the adjustment cylinder.
6
b.
i .
nStallation
