AGILITY Removal

Warning: DO NOT remove the AGILITY while the individual is seated in the wheelchair.
:
Option A
If the wheelchair canes have push handles or other
equipment that may interfere with installation:
1) Use the Allen wrench to loosen the bolt on both sides.
2) Unclip the pivoting band from the adjustment cylinder.
3) Open the pivoting band.
4) Remove the AGILITY from the wheelchair canes.
Note: Refer to agility i
nStallation

Troubleshooting

For additional assistance, contact your clinical caregiver, distributor, or ROHO, Inc.
- Make sure the mounting hardware is flush against the wheelchair canes.
Not able to
correctly attach
- Make sure that the Fixed Hardware is the same height on both sides. Use a tape measure or ruler, if necessary.
components
- The normal installation location of the Fixed Hardware is on the back side of the canes. If a rigidizer bar
during agility
interferes with the Fixed Hardware when installed in the normal location, the Fixed Hardware may be installed
i .
nStallation
on the front side of the canes. In either orientation, the left (L) and right (R) Fixed Hardware should be correctly
located from the viewpoint of the installer.
- Make sure the mounting hardware is flush against the wheelchair canes.
Not able to
correctly attach
- Make sure that the width is set appropriately for the wheelchair. The distance between wheelchair canes may
or secure
vary. If the Fixed Hardware will not correctly attach and secure to the wheelchair canes, a width adjustment
components
may be needed. Adjust the width as described in agility i
during agility
ideal width position for your wheelchair.
i .
nStallation
- If you are not able to secure the Fixed Hardware on the wheelchair canes, you may need to use Cane Sleeves.
(See W
- Make sure the Fixed Hardware -- (left (L) and right (R) -- are on the correct sides.
Not able to
correctly attach
- Make sure the width/height adjustment nuts are in the same position in the triangle brackets. Use the
components
reference grooves as guides, which are below the horizontal slots on the triangle brackets. (See agility
during agility
i
nStallation
i or
nStallation
- Make sure that the Fixed Hardware is the same height on both sides. For each side, count the number of squares
h a .
eight djuStMent
openings that are visible in the sliding height adjustment bar (See h
- Make sure that the left (L) and right (R) depths are equal. Compare the markers on the top of the triangle
Not able to
correctly attach brackets.
components
- Make sure that the left (L) and right (R) hardware are rotated to the same angle. Compare the markers on the
during S
eat
front of the hardware.
d a
epth and ngle
a .
djuStMent
ROHO AGILITY Back System Fixed Hardware Operation Manual
for reference images.
c c .)
heelchair ane oMpatibililty
.)
:
Option B
If the wheelchair canes do not have push
handles or other equipment that may interfere with removal:
1) Use the Allen wrench to loosen but do not remove the
bolt on both sides.
2) Slide the pivoting bands off of the canes.
. It may take a few attempts to find the
nStallation
eight
12
a or p d .)
djuStMent artS etail
