TRIGGER ADJUSTMENT

Trigger adjustment
The trigger has adjustments for microswitch activation point and pre travel.
Pre travel adjustment. Use a 3/32" hex key to remove the frame screws. Carefully unplug the solenoid harness. Use a 1/16" hex key
to adjust the set screw on top of the trigger.
Microswitch activation adjustment. using a 3/64" hex key to adjust the set screws in the trigger. Please make sure to leave enough
space for the screw to travel. Setting the screw too deep will damage the microswitch while fi ring.
Tournament Lock
The tournament lock is located inside the upper right of the LED on
the foregrip, after removing the grip cover. This feature prevents
users from entering programming mode while in the fi eld.
While the gun is in the specifi c fi ring mode, press and hold the lock
switch for 2 seconds to toggle it on or off. The LED will fl ash green
to indicate it is locked or red to indicate it is unlocked. When the
lock is off, you can enter programming mode by turning the board
off, then turning it on while the trigger is held.
