Valken Code Manual page 15

Item Description Item
1 Main Body
2 Feedneck Body
3 Feedneck lever
4 Feedneck nut
5 BHCS 6-32 X .125
6 SHCS 10-32 X .625
7 SHCS 10-32 x .375
8 Ball Detent Cover-Right
9 Ball Detent Cover- Left
10 Ball Detent
11 BHCS 3-48 X .125
12 O Ring-020/70 Buna
13 O Ring-017/70 Buna
14 O Ring-017/90 Urethane
15 Bolt-Front
16 O Ring-015/90 Urethane
17 O Ring 16mm x 2mm ID 70 Urethane
18 O Ring-012/90 Urethane
19 Ram Bumper
20 BH Screw M3 0.5 X 10
21 Valve
22 O Ring-009/90 Urethane
23 O Ring- 21mm x 1mm ID 70 BUNA
24 Back Cap
25 Valve Shaft
26 Back Cap Screw
27 Back Cap lock nut
28 O Ring-008/90 Urethane
CODE SCHEMATICS
Description Item
29 Back Cap lock spring 57
30 Back Cap Lock pin 58
31 Set Screw M2 0.5 X 0.45 59
32 Back Cap Button shaft 60
33 Back Cap Button 61
34 19mm*1mm 70 BUNA 62
35 ASA Adapter 63
36 REG Body 64
37 Oring 004/70 Buna 65
38 O Ring-010/90 Urethane 66
39 BH Screw M2 0.4 X 12 Philips 67
40 O Ring-011/ 90 Urethane 68
41 O Ring-014/70 Buna 69
42 Regulator Piston Guide 70
43 O Ring-014/90 Urethane 71
44 Regulator Piston 72
45 Seal 73
46 Regulator Spring 74
47 Regulator Vent Adjuster Piston 75
48 Retaining Ring INT 9mm 76
49 Barrel 77
50 O Ring -4mm x 1mm ID 70 BUNA 78
51 Rubber Seal 79
52 Air Transfer Plate 80
53 Grip 81
54 Macro Hose 82
55 Solenoid Body 83
56 Set Screw 10-32X5/16 84
valken.com valken.com valken.com
Description Item
BHCS 6-32 X .250 85
Regulator Cover 86
Frame 87
Cover Plate Regulator 88
Seal Rubber Regulator 89
Spring OPP Regulator 90
Seal Regulator 91
Trigger 92
Set Screw 4-40 X .3125 93
Set screw 8-32 x .1875 94
6-32x 16.5mm set screw 95
#N/A 96
Foregrip Left 97
Foregrip Right 98
Feedneck tube 99
SH M2 0.4 X 18 100
Foregrip End Cap
O Ring-2mm x 1mm ID 70 BUNA
Micro Switch
5mm x 1.5mm Magnet
Wire Harness assembly
Foregrip sleeve
FH Screw 6-32 x 3/8
ASA On/Off Lever
BHCS 6-32 X .3125
ASA Guide
ASA Pin
O Ring 006/90 Urethane
Description
ASA Plug
Fliter Cap
Air Fliter
BHCS 8-32 X .3125
BH M2 0.4 X 4
Light Pipe
Solenoid Screw
Regulator Release spring
1/8" ball bearing
Solenoid
Circuit Board A
Circuit Board B
Circuit Board C
Wire Harnesses-A
Wire Harnesses-B
O Ring-011/ 70 Buna
