The Gotcha Gun is a 50cal low impact spring powered gun, designed to be maintained by
the operator. This pictorial guide is designed to help users disassemble and reassemble
the gun, install new parts, and maintain the gun.

reassembly.

1. Unscrew the barrel shown by the Blue arrow.
2. Unscrew the 10 screws shown by the Black arrows in white circles.
3. Carefully separate the 2 casings keeping an eye out for anything that springs out.
Below is a picture of a correctly reassembled Gotcha marker.
Please note when removing the top cover some of the parts may spring out.
It is advisable to put a cloth over the gun, this will prevent the loss of some
of the small parts.
