- Page 1 Repair Manual ( Model : RPHA 70 Mechanism repair) Date : 1 May, 2017 (Rev.01) Division : Quality Team Quality Team...
- Page 2 ■ RPHA 70 Mechanism repair 1. Model : RPHA 70 2. Repair instruction 1) When sun-visor fell out [ Step 1 ] If the mechanism lever doesn’t move, sun-visor should pop out. Push completely the each side of sun-visor. -. The picture shows the sun-visor cannot come in.
- Page 3 ■ RPHA 70 Mechanism repair 2) When the sun-visor doesn’t move, although the mechanism lever moves. [ Step 1 ] Prepare the below tools. If you don’t have them, just use similar ones. [ PEAK ] [ FLAT DRIVER ] [ Step 2 ] Push SV lever backward and remove sun-visor, then check if wire-ball is fell out of holder-SV.
- Page 4 ■ RPHA 70 Mechanism repair [ Step 3 ] Insert wire-ball into the holder-SV Wire-ball Flat driver Peak Peak -. Put the wire-ball using flat driver between the gap. -. Make a gab with peak. [ Step 4 ] Assemble the sun-visor -.
