Overload Protection; Current Unbalance Protection - Deif Multi-line 2 Description Of Options

GPU, GPC, PPU
Alarm settings relate to the nominal power setting (menu 4012).
1260 Generator overload 1 protection
No.
1261 Overload 1
1262 Overload 1
1263 Overload 1
1264 Overload 1
1265 Overload 1
1270 Generator overload 2 protection
No.
1271 Overload 2
1272 Overload 2
1273 Overload 2
1274 Overload 2
1275 Overload 2
1390 Generator overload 3 protection
No.
1391 Overload 3
1392 Overload 3
1393 Overload 3
1394 Overload 3
1395 Overload 3
Overload 3 is not included in the parameter shift function. (Please refer to the
Designers Reference Handbook.)
Alarm settings relate to the nominal current setting (menu 4013).
1280 Generator current unbalance protection
No.
1281 Current unbalance
1282 Current unbalance
1283 Current unbalance
1284 Current unbalance
1285 Current unbalance
DEIF A/S

Overload protection

Setting
Set point
Delay
Relay output A
Relay output B
Enable
Setting
Set point
Delay
Relay output A
Relay output B
Enable
Setting
Set point
Delay
Relay output A
Relay output B
Enable

Current unbalance protection

Setting
Set point
Delay
Relay output A
Relay output B
Enable
Option C1, Generator add-on protection package
Min. setting Max. setting
10.0% 200.0%
0.1 s 100.0 s
R0 (none) Option
dependent
R0 (none)
OFF ON
Min. setting Max. setting
10.0% 200.0%
0.1 s 100.0 s
R0 (none) Option
dependent
R0 (none)
OFF ON
Min. setting Max. setting
10.0% 200.0%
0.1 s 100.0 s
R0 (none) Option
dependent
R0 (none)
OFF ON
Min. setting Max. setting
0.0% 100.0%
0.1 s 100.0 s
R0 (none) Option
dependent
R0 (none)
OFF ON
Factory
setting
100.0%
10.0 s
R2 (relay 2)
R0 (none)
OFF
Factory
setting
110.0%
5.0 s
R2 (relay 2)
R0 (none)
OFF
Factory
setting
120.0%
5.0 s
R2 (relay 2)
R0 (none)
OFF
Factory
setting
30.0%
10.0 s
R2 (relay 2)
R0 (none)
OFF
