Voltage Protections - Deif Multi-line 2 Description Of Options

GPU, GPC, PPU
Alarm settings relate to the nominal voltage setting (menu 4014), phase-phase
measurements.
1100 Generator high voltage 1 protection
No.
1101 Gen. high volt. 1
1102 Gen. high volt. 1
1103 Gen. high volt. 1
1104 Gen. high volt. 1
1105 Gen. high volt. 1
1110 Generator high voltage 2 protection
No.
1111 Gen. high volt. 2
1112 Gen. high volt. 2
1113 Gen. high volt. 2
1114 Gen. high volt. 2
1115 Gen. high volt. 2
1120 Generator low voltage 1 protection
No.
1121 Gen. low volt. 1
1122 Gen. low volt. 1
1123 Gen. low volt. 1
1124 Gen. low volt. 1
1125 Gen. low volt. 1
1130 Generator high voltage 2 protection
No.
1131 Gen. low volt. 2
1132 Gen. low volt. 2
1133 Gen. low volt. 2
1134 Gen. low volt. 2
1135 Gen. low volt. 2
DEIF A/S

Voltage protections

Setting
Set point
Delay
Relay output A
Relay output B
Enable
Setting
Set point
Delay
Relay output A
Relay output B
Enable
Setting
Set point
Delay
Relay output A
Relay output B
Enable
Setting
Set point
Delay
Relay output A
Relay output B
Enable
Option C1, Generator add-on protection package
Min. setting Max. setting
90.0% 120.0%
0.1 s 100.0 s
R0 (none) Option
R0 (none) dependent
OFF ON
Min. setting Max. setting
90.0% 120.0%
0.1 s 100.0 s
R0 (none) Option
dependent
R0 (none)
OFF ON
Min. setting Max. setting
80.0% 100.0%
0.1 s 100.0 s
R0 (none) Option
R0 (none) dependent
OFF ON
Min. setting Max. setting
50.0% 100.0%
0.1 s 100.0 s
R0 (none) Option
dependent
R0 (none)
OFF ON
Factory
setting
103.0%
10.0 s
R0 (none)
R0 (none)
OFF
Factory
setting
105.0%
5.0 s
R0 (none)
R0 (none)
OFF
Factory
setting
97.0%
10.0 s
R0 (none)
R0 (none)
OFF
Factory
setting
95.0%
5.0 s
R0 (none)
R0 (none)
OFF
Page 7 of 10
