Electromechanical Control Business Division
Product description
Part Number
Panasonic's part number
Country of origin
Application
Model number
Magi'c Box
User manual
Industrial Solutions Company
Panasonic Corporation
Magi'c Box
-
-
Japan
Consumer wireless control system
ZERS1901
Advertisement
Related Manuals for Panasonic Magi’c Box
Summary of Contents for Panasonic Magi’c Box
- Page 1 Magi’c Box User manual Electromechanical Control Business Division Industrial Solutions Company Panasonic Corporation Product description Magi’c Box Part Number Panasonic’s part number Country of origin Japan Application Consumer wireless control system Model number ZERS1901...
-
Page 2: System Overview
1. System Overview This product is a two-button switch unit used in consumer wireless control system. When the switch button is pressed by the operation of a lever etc. into which this product is embedded, electric power is generated by its mechanical operation. The generated electric power is used to transmit information such as which of the two buttons is pressed using 2.4GHz to a wireless receiver of a wireless control system installed at a remote location. - Page 3 1.1. Precautions This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 4 2. Magi’c Box Overview The following pictures shows the Magi’c box appearance. It has two button, A and B. It transmit data when these buttons are pushed. B Button A Button Side Front Back Side Bottom Label Fig.2 Pictures of Magi’c box...
- Page 5 3. Test Receiver The following pictures shows the test receiver for theMagi’c box switch. Antenna LED Indicator USB Connector Power switch Fig.2 Pictures of Test Receiver 3.1. LED Test receiver has three LED and those display is defined as follows. LED name Lights up Blink...
- Page 6 4. Setup of test receiver 4.1. Installing USB driver to PC Prior to connect the test receiver to PC, please install the USB driver which is provided by FTDI, D2XX Direct driver (CDM v2.12.28 WHQL Certified.zip) to you PC. The driver should be for Windows OS 64bit version. 4.2.
- Page 7 4.3. Setting of Test receiver (1) Power slide switch should be set to USB side (2) Connect test receiver to PC by USB cable (3) Check if the power indicator lights up or not. (4) Start a terminal software, like “tera term” on PC (5) Set the the terminal software to be as follows Serial port communication Baud rate : 115200...
- Page 8 4.4. Connecting serial port of test receiver with PC Push the button as follows to connect serial port of test receiver with PC. Push the button until the display gets “Port Close” Fig.5 Connecting serial port test receiver with PC 4.5 Paring Magi’c box to test receiver (1) Enter the address of Magi’c box that you want to pair to yellow box.
- Page 9 Fig.6 Paring Magi’c box to test receiver...
- Page 10 5 Logout message The example of Logout messages are shown as below. If the pairing has not been completed, the payload cannot be decrypted as the third line message. Time stamp Rx OK Sequence num Payload( not decrypted) Log out RSSI Fig.7 Logout message example when pairing is not complete Time stamp...
- Page 11 6 Contacts (1) USA Panasonic Industrial Devices Sales Company of America Address：205 Ravendale Drive, Mountain View, CA 94043 +1-201-341-6081 (2) Japan Electromechanical Control Business Division Industrial Solution Company Panasonic Corporation Address：1006 Oaza Kadoma Kadoma City, Osaka 571-8506 +81-50-3487-8129...
