5 Logout message
The example of Logout messages are shown as below.
If the pairing has not been completed, the payload cannot be decrypted as the third
line message.
Time stamp
Log out
Fig.7 Logout message example when pairing is not complete
Time stamp
Log out
10: Decrypted success
Fig.8 Logout message example when pairing is complete
Rx OK Sequence num
Magi'c box address
Payload( not decrypted)
RSSI
SW A or B
RSSI
Decrypted payload
