4.4. Connecting serial port of test receiver with PC
Push the button as follows to connect serial port of test receiver with PC.
Fig.5 Connecting serial port test receiver with PC
4.5 Paring Magi'c box to test receiver
(1) Enter the address of Magi'c box that you want to pair to yellow box.
The length of address should be 12 characters 0-9, a-f
(2) Push the "generate initial key" button
(3) Push the "Write" button
(4) Push the "Read" button to check if writing has been done correctly.
(5) Push the "Key exchange" button
(6) Push the Magi'c box button several times.
Push the button until the
display gets "Port Close"
