Using the Auto-Adjustment Function (Analog Input)

When first setting up the monitor, when conducting a Factory Reset of the computer, or whenever you change the
resolution of the monitor, the Auto-Adjustment feature will automatically engage, and attempt to optimize your
screen for you.
You may also optimize the screen performance for the VGA (analog) input at any time by using the
Adjustment from the OSD Main Menu (press the
the auto-adjustment pattern software utility on the disc provided.
Do not use this procedure if the monitor is using an input other than VGA. If the monitor is using a VGA (analog)
input, this procedure can correct the following image quality conditions:
• Fuzzy or unclear focus
• Ghosting, streaking or shadowing effects
• Faint vertical bars
• Thin, horizontal scrolling lines
• An off-center picture
To use the auto-adjustment feature:
1.
Allow the monitor to warm up for 20 minutes before adjusting.
2.
Do Auto-Adjustment
• You can also press the Menu button, then select Image Control > Auto-Adjustment from the OSD Main
Menu.
• If the result is not satisfactory, continue with the procedure.
3. Insert the disc in the disc drive. The disc menu is displayed.
4. Select Open Auto-Adjustment Utility. The setup test pattern is displayed.
5. Do Auto-Adjustment
6. Press the
NOTE:
The auto-adjustment test pattern utility can be downloaded from http://www.hp.com/support.
24 Appendix B Support and troubleshooting
of image control
of image control to produce a stable, centered image.
ESC key or any other key on the keyboard to exit the test pattern.
Menu button, then select Image Control > Auto-Adjustment) and
Auto-
