Table 1: Front Panel OMX-SW6x1B 6x1 Vertical Interval Switcher Features

# Feature
1 Power Switch
1
2 IN Buttons
3 Internal Cable EQ. Trimmer
4 Internal LEVEL Trimmer

Table 2: Rear Panel OMX-SW6x1B 6x1 Vertical Interval Switcher Features

# Feature
5 Ext. Sync BNC Connector
6 IN BNC Connectors
7 AUDIO L IN-1-6 Terminal
Block Connectors
8 OUT Left Terminal Block
Connector
9 RS-485 Terminal Block Port
10 AUDIO R IN-1-6 Terminal
Block Connectors
11 OUT BNC Connector
12 To NEXT DB 9 port
13 REMOTE DB 15 port
14 To PC DB 9 port
15 SETUP Dipswitches
16 OUT Right Terminal Block
Connector
17 Power Connector with Fuse
1 Selected button illuminates
2 Insert a screwdriver into the small hole and carefully rotate it, trimming the appropriate level
3 See section 7.4
Your OMX-SW6x1B 6x1 Vertical Interval Switcher
Illuminated switch supplying power to the unit
Select the input to switch to the output (from 1 to 6)
Internally located and accessed through hole on the underside
the machine. It allows, if required, cable equalization adjustment
Internally located and accessed through hole on the underside
the machine. It allows, if required, output level adjustment
Connect to the external sync/composite video source
Connect to the composite or single component
Connect the left stereo audio input signals (from 1 to 6)
Connect to the left channel audio output
For bi-directional communication with another switcher or PC via
the RS-485 interface
Connect the right stereo audio input signals (from 1 to 6)
Connect to video acceptor
Used for looping to the next switcher
Used for remote contact closure control
Connects to the PC or other serial controller
Dipswitches for setting the machine #
Connect to the right channel audio output (three left pins; the three
right pins are not used)
AC connector enabling power supply to the unit
Function
Function
4
2
of
2
of
3
video sources
