CY3686 EZ-USB
1
Unpack the kit contents. Using the CD/DVD
provided in the kit, install the kit contents and
Keil uVision IDE.
3
Ensure jumpers J3-J14 and J16 are enabled,
write protect switch SW1 is in the OFF position,
and the NX2LP IC pad U1 is unpopulated.
®
NX2LP-Flex™ DEVELOPMENT KIT
QUICK START GUIDE
2
Set the switches on the FX2LP base board.
SW2 is set to the EEPROM position and
SW1 is set to the large EEPROM position.
4
Stack up the FX2LP base board, the
prototype board (optional), and the NX2LP
flex board. Connect it to the host PC. The
device enumerates as a removable drive
in 'My Computer'. Try transferring data to
and from the drive.
Advertisement
Related Manuals for Cypress EZ-USB NX2LP-Flex CY3686
Summary of Contents for Cypress EZ-USB NX2LP-Flex CY3686
- Page 1 ® CY3686 EZ-USB NX2LP-Flex™ DEVELOPMENT KIT QUICK START GUIDE Unpack the kit contents. Using the CD/DVD Set the switches on the FX2LP base board. provided in the kit, install the kit contents and SW2 is set to the EEPROM position and Keil uVision IDE.
- Page 2 NAND Flash Chip jumpers for enable/disable For the latest information about this kit visit www.cypress.com/go/CY3686 © 2012 Cypress Semiconductor Corporation. All rights reserved. All trademarks or registered trademarks referenced herein are the properties of their respective owners. DOC#: 001-81965 REV **...
